Hydraulic Quick Connect Nipple, Carbon Steel, ISO 5675, 3/4" x 3/4-14, Female NPT, 2.32" Length, 3625PSI

                    (Pack of
                    1)

The integrity of your connection is only as good as the quality of your coupler or nipple. AG couplers and nipples provide the quality and reliability you need. They feature a quality design most commonly used in agricultural applications and are also suitable for use in construction, forestry equipment and mineral oil hydraulic systems.
 Carbon steel body with yellow zinc plating
 Mating parts are hardened
 Nitrile O-ring seals
 Ball seal allows proper coupler function in presence of dirt, oils, etc.
 Easy coupling and uncoupling
 Though these are not swivel couplers, the two halves can rotate to reduce hose torsion
 Temperature range: 40°F to +250°F (40°C to +121°C)
Dixon: AG-SeriesPioneerParker: 4000 SeriesFaster: NS
Frequently Bought Together


                      Hydraulic Cap Nut, 7/8-14"(10) Female JIC SAE 37 Degree Flare
Couldn't load pickup availability


                      MegaCrimp Crimp-On Coupling 1/2" x 3/4-16
Couldn't load pickup availability


                      Crimp-On Hose Coupling 3/4" x 1-1/16-12
Couldn't load pickup availability


                      DOT Connector Male Brass 1/4 x 1/4-18
Couldn't load pickup availability


                      Pipe Coupling Brass 3/8-18 x 3/8-18
Couldn't load pickup availability


                      DOT Connector Male Brass 1/4 x 1/8-27
Couldn't load pickup availability


                      Hydraulic Quick Connect Coupler 3/8" x 3/8-18
Couldn't load pickup availability


                      Hydraulic Quick Connect Coupler 3/8" x 3/8-18
Couldn't load pickup availability


                      Hydraulic Quick Connect Nipple Steel 3/8" x 3/8-18
Couldn't load pickup availability


                      SAE Flat Washer Thru-Hardened Steel 3/8"
Couldn't load pickup availability


                      SAE J995C Locknut with Nylon Insert Grade 8 1/4-20
Couldn't load pickup availability


                      Vision Pro Super
Couldn't load pickup availability
Product Description
The integrity of your connection is only as good as the quality of your coupler or nipple. AG couplers and nipples provide the quality and reliability you need. They feature a quality design most commonly used in agricultural applications and are also suitable for use in construction, forestry equipment and mineral oil hydraulic systems. Carbon steel body with yellow zinc plating
 Mating parts are hardened
 Nitrile O-ring seals
 Ball seal allows proper coupler function in presence of dirt, oils, etc.
 Easy coupling and uncoupling
 Though these are not swivel couplers, the two halves can rotate to reduce hose torsion
 Temperature range: 40°F to +250°F (40°C to +121°C)
Dixon: AG-SeriesPioneerParker: 4000 SeriesFaster: NS
Technical Specifications
| Item#: | 28626 |
|---|---|
| Hydraulic/Pneumatic | Hydraulic |
| Description | Quick Coupling |
| Type | Nipple |
| Style | ISO 5675 |
| Body Size | 3/4 " |
| Thread Size | 3/4-14 |
| Thread Style | Female NPT |
| Burst Pressure | 14,500 PSI |
| Seal Material | Nitrile (Buna-N) |
| Material | Carbon Steel |
| Flow | 28 gal/min |
| Length | 2.32 " |
| Temperature Range | -40 to 250 F |
| Working Pressure | 3,625 PSI |
| Hex Size | 1.42 " |
| Maximum Diameter | 1.52 " |
| Coupled Length | 4.66 " |
| UNSPSC #: | 27121701 |
| TAA Compliant: | Yes |
| Weight: | 0.47 lb |
