Hydraulic Quick Connect Nipple, Steel, ISO 16028, 3/4" x 1-11-1/2, Female NPTF, 3.25" Length, 3625PSI
(Pack of 1)

Lawson Products

Keep hydraulic connections clear in dirty conditions with this Quick Connect Nipple. The flat face design wipes clean easily and operates successfully in applications involving high pressure pulses. Heavy-duty locking sleeve provides greater strength and prevents accidental disconnection, while non-spill design guards against fluid loss during connection and disconnection. Ideal for use in agriculture, construction, mobile equipment, general industrial, mining and nuclear equipment. To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.
• Zinc-plated steel body
• PTFE and nitrile rubber seals
• Conforms to ISO 16028 Standards
• Operating temperature range: –4°F to +212°F (–20°C to +100°C)
• Meets or exceeds HTMA requirements
Dixon: HT-Series
To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.

Read More

Frequently Bought Together


Hydraulic Quick Connect Coupler 3/8" x 1/2-14

Item#: 29971

Hydraulic Quick Connect Coupler 3/4" x 1-11-1/2

Item#: 29973

Z Series Crimp-On Hose End 3/4" x 1-3/16-12

Item#: 16624

Hydraulic Quick Connect Nipple Steel 1/4" x 1/4-18

Item#: 29974

Hydraulic Quick Connect Coupler 3/8" x 1/2-14

Item#: 29971

Hydraulic Quick Connect Coupler 3/4" x 1-11-1/2

Item#: 29973

Hydraulic Cap Nut, 3/4-16"(08) Female JIC SAE 37 Degree Flare

Item#: 86151

Hydraulic Cap Nut, 7/8-14"(10) Female JIC SAE 37 Degree Flare

Item#: 86152

MegaCrimp Crimp-On Coupling 1/2" x 3/4-16

Item#: 62885

DOT Elbow Male Nylon 1/4 x 1/8-27

Item#: 91794

DOT Connector Male Brass 1/4 x 1/4-18

Item#: 57505

Pipe Coupling Brass 3/8-18 x 3/8-18

Item#: 5290

Hydraulic Quick Connect Coupler 3/8" x 3/8-18

Item#: 29970

Hydraulic Quick Connect Nipple Steel 3/8" x 3/8-18

Item#: 11996

Hydraulic Quick Connect Nipple Steel 1" x 1-11-1/2

Item#: 11999

Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece

Item#: DY89320050

SAE Flat Washer Thru-Hardened Steel 3/8"

Item#: 88437

SAE J995C Locknut with Nylon Insert Grade 8 1/4-20

Item#: 53979

Product Description

Keep hydraulic connections clear in dirty conditions with this Quick Connect Nipple. The flat face design wipes clean easily and operates successfully in applications involving high pressure pulses. Heavy-duty locking sleeve provides greater strength and prevents accidental disconnection, while non-spill design guards against fluid loss during connection and disconnection. Ideal for use in agriculture, construction, mobile equipment, general industrial, mining and nuclear equipment. To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.
• Zinc-plated steel body
• PTFE and nitrile rubber seals
• Conforms to ISO 16028 Standards
• Operating temperature range: –4°F to +212°F (–20°C to +100°C)
• Meets or exceeds HTMA requirements
Dixon: HT-Series
To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.

Technical Specifications

Item#: 29978
Hydraulic/Pneumatic Hydraulic
Description Quick Coupling
Type Nipple
Style ISO 16028
Standards ISO 16028
Body Size 19mm (3/4")
Thread Size 1-11-1/2
Thread Style Female NPTF
Burst Pressure 14,500 PSI
Seal Material Nitrile
Material Steel
Flow 50 gal/min
Length 3.25 "
Temperature Range -40 to 212 F
Working Pressure 3,625 PSI
Hex Size 1.77 "
Maximum Diameter 1.88 "
Coupled Length 6.04 "
Tip Diameter 1.1785 "
UNSPSC #: 27121701
TAA Compliant: Yes
Weight: 0.94 lb
