Push-to-Connect Connector, Nickel-Plated Brass, 1/4" x 10-32, Tube x Male UNF, 290 PSI
(Pack of
5)
SKU:55720P Item#: 55720P
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.
Frequently Bought Together
Push-to-Connect Union, Nickel-Plated Brass/PBT Resin, 1/4 x 1/4"
Item#: 86781
Couldn't load pickup availability
Square Head Plug Steel Black 1/4-18
Item#: 8675
Couldn't load pickup availability
Merchant Coupling Steel 3/4-14 x 3/4-14
Item#: 8639
Couldn't load pickup availability
Super 77 Hose Clamp SS 1/2 to 1-1/8"
Item#: 85496
Couldn't load pickup availability
Non-Perforated Clamp 316 SS #4 7/16 to 11/16"
Item#: 58832
Couldn't load pickup availability
Ball Check Grease Fitting 90°
Item#: 6203
Couldn't load pickup availability
Push-to-Connect Tee, Nickel-Plated Brass/PBT Resin, 6 x 6 x 6mm
Item#: 98215
Couldn't load pickup availability
Push-to-Connect Connector, Nickel-Plated Brass/PBT Resin, 1/4 x 3/8"
Item#: 62199
Couldn't load pickup availability
Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 5/16 x 3/8"
Item#: 98204
Couldn't load pickup availability
Superbutt Connector 16 to 14 AWG Blue
Item#: 94728
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M12
Item#: 87512
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Item#: A104
Couldn't load pickup availability
Product Description
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.Technical Specifications
| Item#: | 55720P |
|---|---|
| Manufacturer Model #: | 3171 56 20 |
| Configuration | Male Connector |
| Tube Size | 1/4 " |
| Thread Size | 10-32 " |
| Thread Style | UNF |
| Material | Nickel-Plated Brass |
| Internal Hex Size | 2 mm |
| Thread Length | .13 " |
| Working Pressure | 290 PSI |
| Temperature Range | -4 to +175 °F |
| UNSPSC #: | 40183100 |
| TAA Compliant: | Yes |
| Weight: | 0.12 lb |
Product Restrictions
