SPR; Overall Length: 7.55mm; Dia: 5.3mm; Inside Dia: 3.20mm; Head Dia: 7.8mm; Head Style: Solid; Door
(Pack of
10)
SKU:1632570 Item#: 1632570
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.
Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Frequently Bought Together
MCN Series Lead Clip-On Wheel Weight 1/4 oz
Couldn't load pickup availability
Dual Foot Tilt-Lock Air Chuck
Couldn't load pickup availability
Fender Washer Oversized 3/8" ID 1-1/2" OD
Couldn't load pickup availability
Rocker Molding Clip with Sealer Nylon Gray 12mm
Couldn't load pickup availability
Air Inlet Grille/Bumper Fascia Push-Type Retainer
Couldn't load pickup availability
Phillips Slotted Truss Head License Plate Screw
Couldn't load pickup availability
MCN Series Lead Clip-On Wheel Weight 1 oz
Couldn't load pickup availability
Bumper Cover and Fender Shield Push-Type Retainer
Couldn't load pickup availability
Splash Shield Retainer Nylon 1"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 3/8"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Upper Vent Pivot Tubular Rivet
Couldn't load pickup availability
Closed End Rivet 3/16 Diameter. 1/4-3/8 Grip
Couldn't load pickup availability
Window Regulator Roller and Rivet Kit
Couldn't load pickup availability
Product Description
Self-piercing rivets (SPR) join two or more pieces of material using a rivet without a pre-drilled hole. Self-piercing rivets are a semi-tubular rivet driven at high force through the material layers to be joined, into a die which causes the tail of the rivet to flare out and form a joint. The process requires no hole preparation and delivers high static strength similar to, or better than, spot welding. This process produces a fatigue resistant joint that is stronger than spot welding and less susceptible to corrosion. The use of coated, lightweight and high-strength materials, such as galvanized or pre-painted steel and aluminum makes welding these materials difficult and often not possible.Specs are approximate and for identification only. Refer to Ford Service Kit instructions as to the proper SPR for your application.
Technical Specifications
| Item#: | 1632570 |
|---|---|
| Code | PX |
| Type | Self-Piercing Rivet |
| Body Diameter | 5.3 mm |
| Make | Ford |
| OEM Number | W717337-S900 |
| Ford OEM Number | W717337-S900 |
| Flange Diameter | 7.8 mm |
| Rivet Length | 7.55 mm |
| I.D. | 3.20 mm |
| Description | Self-Piercing Rivet |
| Quantity Per Package | 10.0000 |
| F-150 Location | Door |
| Head Style | Solid |
| UNSPSC #: | 31162200 |
| TAA Compliant: | Yes |
| Weight: | 0.02 lb |
