Solid Solder 1/32"
(Pack of
6.0)
Silver-bearing solder with super-active rosin flux
• Low melting temperature: 355°F (179°C) means less chance of heat damage to surrounding parts and circuit boards
• Instant setting helps reduce cold solder joints
• Non-corrosive, non-charring rosin flux core cleans like an acid flux but does not damage delicate printed circuit board traces
• Silver content provides high conductivity
• Excellent tensile and shear strength – up to 25% stronger than 60/40 solders
• Applications: High-vibration electrical connections, sensitive electronic components and circuit chips, battery cables and terminals, large terminal lugs and hard-to-solder materials
Frequently Bought Together
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Clear
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Blue
Couldn't load pickup availability
Acid Core Solder 1/16"
Couldn't load pickup availability
Solid Solder 1/16"
Couldn't load pickup availability
Acid Core Solder 1/16"
Couldn't load pickup availability
Soldering Iron Tip Long Taper Chisel Tip 0.2"
Couldn't load pickup availability
Soldering Iron Pencil Point Tip 120V 23W
Couldn't load pickup availability
Soldering Iron Replacement Chisel Tip 0.13"
Couldn't load pickup availability
Oxy Acetylene Fuel Gas Single Replacement Flint
Couldn't load pickup availability
333 Dissimilar Steel TIG Wire 1/16"
Couldn't load pickup availability
344 Tool Steel TIG Wire 1/16"
Couldn't load pickup availability
Product Description
Silver-bearing solder with super-active rosin flux• Low melting temperature: 355°F (179°C) means less chance of heat damage to surrounding parts and circuit boards
• Instant setting helps reduce cold solder joints
• Non-corrosive, non-charring rosin flux core cleans like an acid flux but does not damage delicate printed circuit board traces
• Silver content provides high conductivity
• Excellent tensile and shear strength – up to 25% stronger than 60/40 solders
• Applications: High-vibration electrical connections, sensitive electronic components and circuit chips, battery cables and terminals, large terminal lugs and hard-to-solder materials
Technical Specifications
| Item#: | P52064 |
|---|---|
| Welding Process | Solder |
| Type | Solid |
| Diameter | 1/32 " |
| Melting Temperature | 354 °F |
| Tensile Strength | 8,700 PSI |
| Color | Gray |
| Description | Dispenser (12 Feet) |
| UNSPSC #: | 23271806 |
| TAA Compliant: | Yes |
| Weight: | 0.25 lb |
Product Restrictions
