Wing-Type Toggle Bolt Anchor, Mushroom Head, Steel, Zinc Finish, 1/2" Drill Size, #10-24 x 3"
(Pack of 50)

SKU:25145 Item#: 25145

Lawson Products

Toggle Bolt Assemblies
• Better spring action and more thread engagement
1. Insert bolt through item to be fastened, thread on wings, then fold wings completely back and insert through hole until wings spring open.
2. Pull back on assembly to hold wings against inside wall – this prevents the wings from spinning while tightening bolt. Tighten bolt firmly with screwdriver.

Check Availability

Quantity

Catalog page#: 6-37

Frequently Bought Together

Conical Screw Anchor Plastic #8 to #10 x 7/8"

Wedge Type Stud Bolt Anchor Steel 3/8 x 3-3/4"

Mini Self-Drilling Wall Anchor Steel 1-1/4"

SAE Flat Washer Thru-Hardened Steel 1/4"

Locknut with Nylon Insert Grade 8 5/16-18

Hex Nut Grade 8 Alloy Steel 1/4-20

Nylon Cable Tie 4" Black

USS Flat Washer Thru-Hardened Steel 5/16"

Stepdown Butt Connector 22 to 18/16 to 14 AWG

Wing Type Toggle Bolt Steel #10-24 x 3"

ALLIGATOR® Anchor Nylon #6 to #10

Wing-Type Toggle Bolt Anchor Steel 1/4-20 x 4"

Product Description

Toggle Bolt Assemblies
• Better spring action and more thread engagement
1. Insert bolt through item to be fastened, thread on wings, then fold wings completely back and insert through hole until wings spring open.
2. Pull back on assembly to hold wings against inside wall – this prevents the wings from spinning while tightening bolt. Tighten bolt firmly with screwdriver.

Technical Specifications

Item#:	25145
Length	3 "
Type	Wall Anchor
Size	3/16X3 "
Diameter	3/16 "
Material	Steel
Head Style	Mushroom
Finish	Zinc
Thread Pitch	24
Drill Size	1/2 "
Anchor Size	3/16 x 3 "
Tensile Proof Test Load In Concrete	350 lb
Shear Proof Test Load	350 lb
Bolt Size	10-24 (3/16") x 3 "
UNSPSC #:	31162103
TAA Compliant:	No
Weight:	1.69 lb
