Home Bolts Hex Flange Bolt Grade 8 3/4-16 x 5"
Bolts

Hex Flange Bolt, Grade 8, Alloy Steel, Zinc Finish, Fine Thread, 1-1/8" Across Flats, 3/4-16 x 5"
(Pack of 2)

Lawson Products

• Available in coarse and fine thread
• Dimensions conform to IFI-111
• 150,000 PSI minimum tensile strength
• Maximum service temperature: 650°F (343°C)
• Specially designed for truck frame bolting
• For use on Freightliner, Mack, Western, White, Autocar, Peterbilt, IHC and other types of heavy equipment

Read More
Check Availability

California Proposition 65: Not Applicable
www.P65Warnings.ca.gov

Catalog page#: 3-58

Frequently Bought Together


Hex Cap Screw Grade 8 7/16-14 x 1-1/2"

Item#: FA68048

Hex Cap Screw 18-8 Stainless Steel 5/16-18 x 1"

Item#: 91025

Hex Cap Screw Grade 8 3/4-10 x 2-1/2"

Item#: FA68117

SAE Flat Washer Thru-Hardened Steel 1/4"

Item#: FA88435

Hex Cap Screw Grade 8 Alloy Steel 3/8-16 x 1-1/2"

Item#: 634

Hex Nut Grade 8 Steel 1/2-13

Item#: FA68404

Hex Flange Bolt Grade 8 5/8-11 x 2-1/4"

Item#: 1586587

Hex Flange Bolt Grade 10.9 M10-1.5 x 50mm

Item#: 59746

Hex Flange Bolt Grade 10.9 M10-1.5 x 80mm

Item#: 59750

Self-Drilling Screw Hex Head #10-16 x 3/4"

Item#: 84931

Flat Washer Grade 12 Thru-Hardened Steel M12

Item#: 87512

USS Flat Washer Thru-Hardened Steel 3/8"

Item#: FA88447

Product Description

• Available in coarse and fine thread
• Dimensions conform to IFI-111
• 150,000 PSI minimum tensile strength
• Maximum service temperature: 650°F (343°C)
• Specially designed for truck frame bolting
• For use on Freightliner, Mack, Western, White, Autocar, Peterbilt, IHC and other types of heavy equipment

Technical Specifications

Item#: 51985
Type Hex Flange Bolt
Diameter 3/4 "
Thread Pitch 16
Thread Fine
Length 5 "
Finish Bright Zinc
Material Alloy Steel
Grade 8
Head Style Hex Flange
Size 3/4-16X5 "
Across Flats 1-1/8 "
Specifications IFI-111
Tensile Strength 150,000 PSI
Maximum Temperature 650 °F
UNSPSC #: 31161620
TAA Compliant: No
Weight: 1.71 lb
