Hydraulic O-Ring Flange Kit, Buna-N, 1.484" ID, 0.139" Thickness, 1-1/4" Port Size, SAE Code 61/62
(Pack of
10)
SKU:12418 Item#: 12418
Nitrile composition O-rings are recommended for hydraulic applications, offering long-lasting resistance to alkaline and salt solutions, oils, gas and water. Not suitable for use with strong oxidizing agents.
• 90 Durometer Buna-N
• Temperature range: –40°F to +250°F (–40°C to +121°C)• Conforms to SAE J514 and MS 16142 specifications
• For use on Split Flange Fittings
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer -
www.P65Warnings.ca.gov
Catalog page#: 8-114
Frequently Bought Together
Hydraulic Cap Nut, 7/16-20"(04) Female JIC SAE 37 Degree Flare
Couldn't load pickup availability
Hydraulic Plug, 7/16-20"(04) Male JIC SAE 37 Degree Flare
Couldn't load pickup availability
Hydraulic Plug 11/16-16 Male ORFS
Couldn't load pickup availability
Z Series Crimp-On Hose End 3/4" x 1-1/16-12
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/4" x 9/16-18
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/2" x 7/8-14
Couldn't load pickup availability
DOT Union Brass 1/2 x 1/2"
Couldn't load pickup availability
Hose Clamp 304 SS 9/16 to 1-1/16"
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 9/16 to 1-1/16"
Couldn't load pickup availability
180-degree Wide Beam Head Light with Side Light
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Stepdown Butt Connector 22 to 18/16 to 14 AWG
Couldn't load pickup availability
Product Description
Nitrile composition O-rings are recommended for hydraulic applications, offering long-lasting resistance to alkaline and salt solutions, oils, gas and water. Not suitable for use with strong oxidizing agents.• 90 Durometer Buna-N
• Temperature range: –40°F to +250°F (–40°C to +121°C)• Conforms to SAE J514 and MS 16142 specifications
• For use on Split Flange Fittings
Technical Specifications
| Item#: | 12418 |
|---|---|
| Style | O-Ring |
| Material | Buna-N |
| Connection Type | SAE Code 61/62 |
| Connection Type A | SAE Code 61/62 |
| Connection Size A | 1-1/4 " |
| Temperature Range | -40 to 250 |
| Flange Size | 1-1/4 (-20) |
| Durometer | 90 |
| I.D. | 1.484 " |
| Thickness | .139 " |
| UNSPSC #: | 27121700 |
| TAA Compliant: | No |
| Weight: | 0.03 lb |
Product Restrictions
California Proposition 65: WARNING: Cancer -
www.P65Warnings.ca.gov
