Home Fittings Instrumentation Elbow 90° 1/8" x 1/8-27
Fittings

Instrumentation Elbow 90° 1/8" x 1/8-27
(Pack of 1.0)

Lawson Products

• Precision tube fittings for the most demanding process control and instrumentation applications
• Positive leak-free seal after repeated assembly
• Heat code traceability on 316 Stainless Steel
• Fully interchangeable with Swagelok® and Parker A-LOK®
• Double ferrule design
• Manufactured to ANSI B31.1 and B31.3 Standards
• ASTM F1387 certified

Read More
Check Availability

California Proposition 65: Not Applicable
www.P65Warnings.ca.gov

Catalog page#: 9-5

Frequently Bought Together


Hose Barb Hose Mender Brass 5/16 x 5/16"

Item#: 96864

Quick Disconnect Coupler Brass 1/4" x 1/4-18

Item#: 54542

Quick Disconnect Plug Steel 3/8" x 1/4-18

Item#: 54552

DOT Elbow Male Nylon 1/4 x 1/8-27

Item#: 91794

Pipe Street Elbow Brass 90° 3/8-18 x 3/8-18

Item#: 5317

Z Series Crimp-On Hose End 3/8" x 9/16-18

Item#: 16613

Instrumentation Elbow 45° 3/8 x 3/8"

Item#: 1343411

Instrumentation Quick Coupler 3/8"

Item#: 59961

Instrumentation Quick Coupler 1/4-18

Item#: 59963

Hose Barb Brass 3/8" x 1/2-14

Item#: 96860

Hose Barb Hose Mender Brass 5/16 x 5/16"

Item#: 96864

Quick Disconnect Coupler Brass 1/4" x 1/4-18

Item#: 54542

SAE J995C Locknut with Nylon Insert Grade 8 1/4-20

Item#: 53979

IFI 100/107 Top Locknut Grade C 5/8-11

Item#: 80933

Lawson Open & Shut Nut & Bolt Loosener, Rust Penetrant, SKU DA6152, 20 oz Aerosol Can

Item#: DA6152

Product Description

• Precision tube fittings for the most demanding process control and instrumentation applications
• Positive leak-free seal after repeated assembly
• Heat code traceability on 316 Stainless Steel
• Fully interchangeable with Swagelok® and Parker A-LOK®
• Double ferrule design
• Manufactured to ANSI B31.1 and B31.3 Standards
• ASTM F1387 certified

Technical Specifications

Item#: 59850
Tube Size 1/8 "
Description Instrumentation Fitting
Fitting Type Compression
Configuration Male Elbow
Angle 90 °
Connection Type A x B Tube x Male NPT
Fitting Dimension A 1/8 "
Fitting Dimension B 1/8-27
Material Stainless Steel
Swagelok Number 200-2-2
Thread Style Male NPT
Thread Size 1/8 "
UNSPSC #: 27131600
TAA Compliant: No
Weight: 0.09 lb

Product Restrictions

California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
