Mid-Range Panel-Mount Circuit Breaker Type III 20A
(Pack of
1.0)
• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog page#: 19-14
Frequently Bought Together
MINI Circuit Breaker Type II-15A 12V
Couldn't load pickup availability
MINI Circuit Breaker Type II-10A 12V
Couldn't load pickup availability
Post-Style Circuit Breaker with Bracket 25A 12V
Couldn't load pickup availability
Nylon Cable Tie 11.75" Black
Couldn't load pickup availability
Nylon Cable Tie 15.5" Black
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Clear
Couldn't load pickup availability
ATO/ATC Fuse 10A Red
Couldn't load pickup availability
MINI Fuse 10A Red
Couldn't load pickup availability
ATO/ATC Fuse 20A Yellow
Couldn't load pickup availability
Nylon Cable Tie 11.75" Black
Couldn't load pickup availability
Nylon Cable Tie 15.5" Black
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Clear
Couldn't load pickup availability
Product Description
• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Type III Manual Reset type allows opening the circuit path without disconnecting it from the power source
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles
Technical Specifications
| Item#: | 50258 |
|---|---|
| Style | Mid-Range Panel-Mounted Circuit Breakers |
| Amperage | 20 A |
| Volts | 32 DC |
| Approvals | Ignition protected (ABYC E-9/SAE J1171) |
| Description | Type III Manual Reset |
| Type | Electrical |
| UNSPSC #: | 39121601 |
| TAA Compliant: | Yes |
| Weight: | 0.11 lb |
