Plastic Covered Primary Wire, Vinyl Plastic, 16 AWG, 60 Volts, Black, 100' Length, SAE J1128 GPT Cable
(Pack of
1)
SKU:5554K Item#: 5554K
• Special vinyl plastic cover is not affected by oil, grease, gasoline, other fuels or chemicals
• Will remain soft and pliable in most weather conditions
• SAE J1128 Type GPT
• Temperature rating: –40°F to +221°F (–40°C to +105°C)
• RoHS compliant
• Recommended for trucks, tractors, cars and general service
• For use at 60V or less
NOTE: Primary wire is not recommended in high voltage applications.
Couldn't load pickup availability
Catalog page#: 17-4
Frequently Bought Together
Tru-Shrink Heat Shrink Tubing 14 to 6 AWG Black
Couldn't load pickup availability
Connector Housing 20A 2-Wire Shroud
Couldn't load pickup availability
DT Series Receptacle 13A 2 Contacts
Couldn't load pickup availability
Cross Linked Primary Wire 16 AWG 100' Blue
Couldn't load pickup availability
Cross Linked Primary Wire 12 AWG 100' White
Couldn't load pickup availability
Cross Linked Primary Wire 18 AWG 100' Brown
Couldn't load pickup availability
Plastic Covered Primary Wire 18 AWG 100' Blue
Couldn't load pickup availability
Plastic Covered Primary Wire 18 AWG 100' Pink
Couldn't load pickup availability
Plastic Covered Primary Wire 14 AWG 100' Purple
Couldn't load pickup availability
Cross Linked Primary Wire 16 AWG 100' Brown
Couldn't load pickup availability
Cross Linked Primary Wire 18 AWG 100' White
Couldn't load pickup availability
Jacketed Parallel Primary Wire 16 AWG 4C 100'
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 1/2"
Couldn't load pickup availability
180-degree Wide Beam Head Light with Side Light
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/8"
Couldn't load pickup availability
Product Description
• Special vinyl plastic cover is not affected by oil, grease, gasoline, other fuels or chemicals• Will remain soft and pliable in most weather conditions
• SAE J1128 Type GPT
• Temperature rating: –40°F to +221°F (–40°C to +105°C)
• RoHS compliant
• Recommended for trucks, tractors, cars and general service
• For use at 60V or less
NOTE: Primary wire is not recommended in high voltage applications.
Technical Specifications
| Item#: | 5554K |
|---|---|
| Type | Wire |
| Wire Gauge | 16 AWG |
| Color | Black |
| Length | 100 ft |
| Package Type | 1 Roll |
| Volts | 60 |
| Temperature Rating | 221 °F |
| Approvals | SAE J1128 Type GPT and RoHS compliant |
| Style | Plastic-covered Primary Wire - Rated 221 F |
| UNSPSC #: | 26121524 |
| TAA Compliant: | No |
| Weight: | 1.19 lb |
