Industrial Tubing, Polyethylene, 1/4" OD x 11/64" ID x 0.04" Wall Thickness, 100' Length, 200PSI, Red
(Pack of
1)
SKU:90327 Item#: 90327
• Resistant to solvents and chemicals
• Non-toxic
• 100 feet per roll
• Temperature range: –100°F to +175°F (–73°C to +79°C)
• Recommended for low pressure air, water and chemical lines
Burst pressure at 73°F (23°C)
Couldn't load pickup availability
Catalog page#: 9-68
Frequently Bought Together
Hex Head Plug Brass 1/2-14 Male NPT
Couldn't load pickup availability
Pipe Coupling Brass 3/8-18 x 3/8-18
Couldn't load pickup availability
Pipe Street Elbow Brass 90° 3/8-18 x 3/8-18
Couldn't load pickup availability
Super 77 Miniature Hose Clamp SS 7/32 to 5/8"
Couldn't load pickup availability
Pipe Bushing Brass 1/2-14 x 1/4-18
Couldn't load pickup availability
DOT Union Brass 3/8 x 3/8"
Couldn't load pickup availability
Push-to-Connect Union, Nickel-Plated Brass/PBT Resin, 6 x 6mm
Couldn't load pickup availability
Push-to-Connect Connector, Nickel-Plated Brass/PBT Resin, 1/4 x 1/8"
Couldn't load pickup availability
Push-to-Connect Union, Nickel-Plated Brass/PBT Resin, 5/16 x 5/16"
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Clear
Couldn't load pickup availability
High Solids Paints Gloss Black
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Product Description
• Resistant to solvents and chemicals• Non-toxic
• 100 feet per roll
• Temperature range: –100°F to +175°F (–73°C to +79°C)
• Recommended for low pressure air, water and chemical lines
Burst pressure at 73°F (23°C)
Technical Specifications
| Item#: | 90327 |
|---|---|
| Configuration | Tubing |
| Material | Polyethylene |
| O.D. | 1/4 " |
| I.D. | 11/64 " |
| Wall Thickness | 0.040 " |
| Working Pressure | 200 PSI |
| Burst Pressure | 600 PSI |
| Length | 100 ft |
| Color | Red |
| Tube Insert | 5389 |
| Quantity Per Package | 1.0000 |
| UNSPSC #: | 40183000 |
| TAA Compliant: | Yes |
| Weight: | 1.1 lb |
