Anchor Shackle, Screw Pin, 5/16", 2,000 lb WLL, Carbon Steel, Orange Powder Coated
(Pack of
2)
SKU:1429879 Item#: 1429879
Screw pin shackles afford quick and easy removal of the screw pin which is secured by torque. While the threaded pin can resist axial forces, it is vulnerable to backing out and the shackle is not reliable in applications where the pin is subjected to a torque or twisting action.
• Carbon steel bodies
• Alloy steel pins
• Working Load Limit and traceability codes shown as permanent marking on body and pin
• All shackles meet or exceed Federal Specification RRC-271F, Type IVA, Grade A, Class 2
• Design factor 6:1
• Desirable in applications where the shackle is frequently removed
CAUTION: Do not exceed working load limits.
Couldn't load pickup availability
Catalog page#: 15-21
Frequently Bought Together
Spring Link, Stainless Steel, 5/16", 280 LB WLL
Couldn't load pickup availability
Eyebolt, Machinery, Self-Colored, 3/8" x 1-1/4"
Couldn't load pickup availability
Screw Eye Light-Duty Trade Size 104 1/2" Eye
Couldn't load pickup availability
Screw Pin Anchor Shackle, 1/2", 4,000 lb WLL
Couldn't load pickup availability
Screw Pin Anchor Shackle, 1/4", 1,000 lb WLL
Couldn't load pickup availability
Connecting Link, Single Strand, Steel, Industry No. 40
Couldn't load pickup availability
Screw Pin Chain Shackle, 1/2", 4,000 lb WLL
Couldn't load pickup availability
Round Pin Anchor Shackle, 3/16", 1,000 lb WLL
Couldn't load pickup availability
Screw Pin Chain Shackle, 1/4", 1,000 lb WLL
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 5/8-11
Couldn't load pickup availability
Interchangeable Hex Bit Set 20Pc Torx
Couldn't load pickup availability
Product Description
Screw pin shackles afford quick and easy removal of the screw pin which is secured by torque. While the threaded pin can resist axial forces, it is vulnerable to backing out and the shackle is not reliable in applications where the pin is subjected to a torque or twisting action.• Carbon steel bodies
• Alloy steel pins
• Working Load Limit and traceability codes shown as permanent marking on body and pin
• All shackles meet or exceed Federal Specification RRC-271F, Type IVA, Grade A, Class 2
• Design factor 6:1
• Desirable in applications where the shackle is frequently removed
CAUTION: Do not exceed working load limits.
Technical Specifications
| Item#: | 1429879 |
|---|---|
| Manufacturer Model #: | M647P |
| Type | Anchor Shackle |
| Style | Screw Pin |
| Body Material | Carbon Steel |
| Finish | Orange Powder Coated |
| Size | 5/16 " |
| Working Load Limit | 2,000 lb |
| Pin Diameter | 3/8 " |
| Pin Material | Alloy Steel |
| Width Between Eyes | 17/32 " |
| Bow Width | 13/16 " |
| Depth | 1-1/4 " |
| UNSPSC #: | 24101641 |
| TAA Compliant: | Yes |
| Weight: | 0.39 lb |
