Weatherhead H280 Hydraulic Hose, 3/8" ID, 0.69" OD, 50' Length, 5300PSI, Vinyl Nitrile, 2-Steel Braided, SAE 100R16S
(Pack of
50)
SKU:50799 06 Item#: 50799 06
• Dura-Tuff premium abrasion resistant hose cover offers 8x greater abrasion resistance than industry standard
• Agency Ratings: SAE 100R17, SAE 100R1, EN 857 1SC
• Fittings Certified: Z-Series
• Agency Approval: MSHA, ABS, USCG and DNV
• Construction:
– Inner Tube: Nitrile
– Reinforcement: Two steel braids
– Cover: Dura-Tuff Premium Abrasion
• Temperature Range:
– Petroleum and Water based fluids: –50°F to +260°F (–46°C to +127°C)
• Application Notes: Hydraulic systems service with petroleum and water-based fluids, for general use
Couldn't load pickup availability
Catalog page#: 8-11
Frequently Bought Together
Hydraulic Quick Connect Coupler 1/4" x 1/4-18
Couldn't load pickup availability
Premium Greasing Accessory 8 Piece Kit
Couldn't load pickup availability
DOT Swivel Elbow Male 360° Brass 1/2 x 3/8-18
Couldn't load pickup availability
Z Series Crimp-On Hose End 3/8" x 7/8-14
Couldn't load pickup availability
Hydraulic Quick Connect Coupler 1/4" x 1/4-18
Couldn't load pickup availability
Premium Greasing Accessory 8 Piece Kit
Couldn't load pickup availability
EC215 Winner Hydraulic Hose Rubber 0.69" x 50'
Couldn't load pickup availability
EC215 Winner Hydraulic Hose Rubber 0.82" x 50'
Couldn't load pickup availability
SAE R16S Hydraulic Hose Rubber 1.09" x 50'
Couldn't load pickup availability
Z Series Crimp-On Elbow Flare 90° 3/8" x 9/16-18
Couldn't load pickup availability
Crimp-On Coupling 3/8" x 11/16-16
Couldn't load pickup availability
Crimp-On Hose Coupling 1/2" x 1/2-14
Couldn't load pickup availability
DOT Compression Union Brass 1/4"
Couldn't load pickup availability
DOT Elbow Male Nylon 3/8 x 1/4-18
Couldn't load pickup availability
Hose Clamp 304 SS 3/4 to 1-3/4"
Couldn't load pickup availability
EC215 Winner Hydraulic Hose Rubber 0.69" x 50'
Couldn't load pickup availability
EC215 Winner Hydraulic Hose Rubber 0.82" x 50'
Couldn't load pickup availability
SAE R16S Hydraulic Hose Rubber 1.09" x 50'
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 3/8"
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
Product Description
• Dura-Tuff premium abrasion resistant hose cover offers 8x greater abrasion resistance than industry standard• Agency Ratings: SAE 100R17, SAE 100R1, EN 857 1SC
• Fittings Certified: Z-Series
• Agency Approval: MSHA, ABS, USCG and DNV
• Construction:
– Inner Tube: Nitrile
– Reinforcement: Two steel braids
– Cover: Dura-Tuff Premium Abrasion
• Temperature Range:
– Petroleum and Water based fluids: –50°F to +260°F (–46°C to +127°C)
• Application Notes: Hydraulic systems service with petroleum and water-based fluids, for general use
Technical Specifications
| Item#: | 50799 06 |
|---|---|
| Industrial / Hydraulic | Hydraulic |
| Type | Rubber - Steel Braided |
| Category / Performance | High Pressure |
| Industry Rating 1 | SAE 100R17 |
| Industry Rating 2 | EN 857 1SC |
| Industry Rating | MSHA, ABS, USCG and DNV |
| Manufacturer Series Number | H280 |
| Manufacturer Series Name | DURA-TUFF |
| I.D. | 3/8 (-6) " |
| Hose O.D. | 0.69 " |
| Working Pressure | 5,800 PSI |
| Burst Pressure | 23,200 PSI |
| Fitting Series | Z Series |
| Bend Radius | 2-1/2 " |
| Inner Tube Material | Nitrile |
| Hose Reinforcement | 2 Steel Braids |
| Hose Cover Material | Nitrile |
| Temperature | High |
| Material | Hydraulic Oil |
| Applications | Hydraulic - Constant Flow |
| Temperature Range | Petroleum based fluids -50F to +260F, Water based fluids -50F to +260 F |
| UNSPSC #: | 40142020 |
| TAA Compliant: | No |
| Weight: | 15.14 lb |
