A Solid Mild Steel .023X10Lbs Current Dcep Gas 75% Ar/25% Co2 Or 100% Co2 Sheilding Gas 30%Elongation 78000 Tensile
(Pack of
10)
SKU:EG60640023 Item#: EG60640023
A solid mild steel wire designed for welding steel in the short-circuit or spray mode. Dura-Weld M is a triple deoxidized wire for use on mill scale and light rust.
• Perfect for sheet metal, structural shapes and thin plate
• Highly deoxidized for high quality welds
• Designed for all grades of low to medium carbon steel
• Controlled temper for consistent feed characteristics
• Copper-coated for good electrical contact and to reduce oxidation
• Tensile Strength: 78,000 PSI/537 Mpa
• Yield Strength: 63,000 PSI/415 Mpa
• Elongation: 30%
• Impact Strength (Charpy) 0°F/-17°C: 70 ft.-lbs.
• Current: DCEP
• Gas: 75% Ar/25% CO2 or 100% CO2
Frequently Bought Together
163 Arc-Cut Synthetic Carbon Arc Electrode
Couldn't load pickup availability
E6011 Mild/Carbon Steel Stick Electrode 5/32"
Couldn't load pickup availability
606 Duraweld M Mig Wire Maintenance Grade Mild Steel Solid Mig Wire
Couldn't load pickup availability
Lawson Open & Shut Nut & Bolt Loosener, Rust Penetrant, SKU DA6152, 20 oz Aerosol Can
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/4-20
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 3/8-16
Couldn't load pickup availability
ER70S-6 Mild/Carbon Steel MIG Welding Wire 0.03"
Couldn't load pickup availability
E7018 Mild/Carbon Steel Stick Electrode 1/8"
Couldn't load pickup availability
344 Tool Steel TIG Wire 1/16"
Couldn't load pickup availability
X-Tractalloy Welding Electrode Non-Conductive Flux 3/32 5/64
Couldn't load pickup availability
777 Stainless Steel Stick Rod Electrode 1/8"
Couldn't load pickup availability
E6013 Mild/Carbon Steel Stick Electrode 1/8"
Couldn't load pickup availability
Product Description
A solid mild steel wire designed for welding steel in the short-circuit or spray mode. Dura-Weld M is a triple deoxidized wire for use on mill scale and light rust.• Perfect for sheet metal, structural shapes and thin plate
• Highly deoxidized for high quality welds
• Designed for all grades of low to medium carbon steel
• Controlled temper for consistent feed characteristics
• Copper-coated for good electrical contact and to reduce oxidation
• Tensile Strength: 78,000 PSI/537 Mpa
• Yield Strength: 63,000 PSI/415 Mpa
• Elongation: 30%
• Impact Strength (Charpy) 0°F/-17°C: 70 ft.-lbs.
• Current: DCEP
• Gas: 75% Ar/25% CO2 or 100% CO2
Technical Specifications
| Item#: | EG60640023 |
|---|---|
| Welding Process | MIG |
| Type | MIG |
| Diameter | .023 " |
| Tensile Strength | 78,000 PSI |
| Yield Strength | 63,000 PSI |
| Base Metal | Mild & Carbon Steel |
| Shielding Gas | 75% Ar/25% CO2 or 100% CO2 |
| Polarity | DCEP |
| Size | .023 " |
| UNSPSC #: | 23271810 |
| TAA Compliant: | No |
| Weight: | 12.08 lb |
