606 Duraweld M Mig Wire Maintenance Grade Mild Steel Solid Mig Wire
606 Duraweld M Mig Wire Maintenance Grade Mild Steel Solid Mig Wire

A Solid Mild Steel .023X10Lbs Current Dcep Gas 75% Ar/25% Co2 Or 100% Co2 Sheilding Gas 30%Elongation 78000 Tensile
(Pack of 33)

Item#: EG60680030

Lawson Products

A solid mild steel wire designed for welding steel in the short-circuit or spray mode. Dura-Weld M is a triple deoxidized wire for use on mill scale and light rust.
• Perfect for sheet metal, structural shapes and thin plate
• Highly deoxidized for high quality welds
• Designed for all grades of low to medium carbon steel
• Controlled temper for consistent feed characteristics
• Copper-coated for good electrical contact and to reduce oxidation
• Tensile Strength: 78,000 PSI/537 Mpa
• Yield Strength: 63,000 PSI/415 Mpa
• Elongation: 30%
• Impact Strength (Charpy) 0°F/-17°C: 70 ft.-lbs.
• Current: DCEP
• Gas: 75% Ar/25% CO2 or 100% CO2

Read More
Check Availability

Frequently Bought Together

1/4

1/4" - 3/4" Cryonitride Spiral Fluted Step Drill - 3/8" Shank

Item#: DY80170030
2.1 Round Head Ratchet 1/4 Drive 168 Tooth, 1/4

2.1 Round Head Ratchet 3/8 Drive 168 Tooth

Item#: DY89285105
Spinning Handmaster Driver Set 5Pc Set, 5 Piece, 1/4 Shank, Spinning Handmaster Driver Set

Spinning Handmaster Driver Set 5Pc Set

Item#: DY89310460
331 Mild and Carbon Steel MIG Welding Wire 0.030

331 Mild and Carbon Steel MIG Welding Wire 0.03"

Item#: CW5130
163 Arc-Cut Synthetic Carbon Arc Electrode

163 Arc-Cut Synthetic Carbon Arc Electrode

Item#: EG16300250
E7018 Mild/Carbon Steel Stick Electrode 3/32

E7018 Mild/Carbon Steel Stick Electrode 3/32"

Item#: 41788
Butt Connector 16 to 14 AWG Blue, Butt Connector, 2-Piece Heat Seal, Polyolefin Insulated, 16 to 14 AWG, 1.45

Butt Connector 16 to 14 AWG Blue

Item#: 92823
180-degree Wide Beam Head Light with Side Light

180-degree Wide Beam Head Light with Side Light

Item#: 1639013
USS Flat Washer Thru-Hardened Steel 7/8

USS Flat Washer Thru-Hardened Steel 3/8"

Item#: 88447
ER70S-6 Mild/Carbon Steel MIG Welding Wire 0.035

ER70S-6 Mild/Carbon Steel MIG Welding Wire 0.035"

Item#: 41758
Oxy Acetylene Fuel Gas Single Replacement Flint, Electro-Zinc Plated

Oxy Acetylene Fuel Gas Single Replacement Flint

Item#: CW1307
Rosin Core Solder 1/16

Rosin Core Solder 1/16"

Item#: 20555
E7018 Mild/Carbon Steel Stick Electrode 5/32

E7018 Mild/Carbon Steel Stick Electrode 1/8"

Item#: 41790
X-Tractalloy Extracting Welding Electrode Non-Conductive Flux 3/16

X-Tractalloy Extracting Welding Electrode Non-Conductive Flux 3/32

Item#: EG00450000
321 Mild and Carbon Steel MIG Welding Wire 0.035

321 Mild and Carbon Steel MIG Welding Wire 0.035"

Item#: CW1931

Product Description

A solid mild steel wire designed for welding steel in the short-circuit or spray mode. Dura-Weld M is a triple deoxidized wire for use on mill scale and light rust.
• Perfect for sheet metal, structural shapes and thin plate
• Highly deoxidized for high quality welds
• Designed for all grades of low to medium carbon steel
• Controlled temper for consistent feed characteristics
• Copper-coated for good electrical contact and to reduce oxidation
• Tensile Strength: 78,000 PSI/537 Mpa
• Yield Strength: 63,000 PSI/415 Mpa
• Elongation: 30%
• Impact Strength (Charpy) 0°F/-17°C: 70 ft.-lbs.
• Current: DCEP
• Gas: 75% Ar/25% CO2 or 100% CO2

Technical Specifications

Item#: EG60680030
Welding Process MIG
Type MIG
Diameter .030 "
Tensile Strength 78,000 PSI
Yield Strength 63,000 PSI
Base Metal Mild & Carbon Steel
Shielding Gas 75% Ar/25% CO2 or 100% CO2
Polarity DCEP
Size .030 "
UNSPSC #: 23271810
TAA Compliant: No
Weight: 37.19 lb
