Eye Bolt, Lifting, M30 x 3.5
(Pack of
1.0)
• Shoulder pattern
• Drop-forged steel
• Manufactured from C-1030 steel
• Heat-treated
Always match working loads when making chain assemblies.
Safe working load capacities for 90° pull not available, as using lift angles exceeding 45° are not recommended for this product. CAUTION: Do not exceed safe working load. Angular lifts should be avoided whenever possible.
Frequently Bought Together
Eyebolt, Machinery, Self-Colored, 1-1/2" x 3-1/2"
Couldn't load pickup availability
Eye Bolt with Nut 5/8" x 6" Long
Couldn't load pickup availability
Shoulder Eyebolt, Machinery, Self-Colored, M7 x 1.0 x 28.5
Couldn't load pickup availability
Eye Bolt with Nut 1/4" x 4" Long
Couldn't load pickup availability
Welded Eye Bolt with Nut, Stainless Steel, 6mm, 400 lb WLL
Couldn't load pickup availability
Eyebolt, With Nut, Galvanized, 3/4" x 12"
Couldn't load pickup availability
Tarp Strap Epdm Rubber with Hooks 28" Long
Couldn't load pickup availability
Tuff-Edge® Web Sling, Polyester, Silver, 6' Length
Couldn't load pickup availability
Wire Rope Sleeve, 3/16", Aluminum
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 3/8-16
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Nutsetter & Bit Set, Magnetic, 22pc
Couldn't load pickup availability
Product Description
• Shoulder pattern• Drop-forged steel
• Manufactured from C-1030 steel
• Heat-treated
Always match working loads when making chain assemblies.
Safe working load capacities for 90° pull not available, as using lift angles exceeding 45° are not recommended for this product. CAUTION: Do not exceed safe working load. Angular lifts should be avoided whenever possible.
Technical Specifications
| Item#: | 59246 |
|---|---|
| Type | Machinery Eye Bolt |
| Style | Shoulder Pattern |
| Material | Forged Steel |
| Thread Size | M30 x 3.5 |
| Eye I.D. | 55 mm |
| Eye O.D. | 112.7 mm |
| Overall Length | 192.8 mm |
| Thread Length | 60 mm |
| Working Load Limit | 6,400 kg |
| UNSPSC #: | 31162600 |
| TAA Compliant: | Yes |
| Weight: | 4.46 lb |
