Hydraulic Quick Connect Nipple Steel 1/2
Hydraulic Quick Connect Nipple Steel 1/2

Hydraulic Quick Connect Nipple, Steel, ISO 16028, 1/4" x 1/4-18, Female NPTF, 1.89" Length, 4350PSI
(Pack of 1)

Item#: 29974

Lawson Products

Keep hydraulic connections clear in dirty conditions with this Quick Connect Nipple. The flat face design wipes clean easily and operates successfully in applications involving high pressure pulses. Heavy-duty locking sleeve provides greater strength and prevents accidental disconnection, while non-spill design guards against fluid loss during connection and disconnection. Ideal for use in agriculture, construction, mobile equipment, general industrial, mining and nuclear equipment. To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.
• Zinc-plated steel body
• PTFE and nitrile rubber seals
• Conforms to ISO 16028 Standards
• Operating temperature range: –4°F to +212°F (–20°C to +100°C)
• Meets or exceeds HTMA requirements
Dixon: HT-Series
To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.

Read More
Check Availability

Catalog page#: 8-83

Frequently Bought Together

DOT Elbow Male 90° Brass 1/4 x 1/4-18, DOT Air Brake Push to Connect Elbow, 90°, Male, Brass, 1/4 x 1/4-18, Tube x Pipe

DOT Elbow Male 90° Brass 3/8 x 1/8-27

Item#: 27186
DOT Swivel Branch Tee Male Brass 3/8 x 3/8 x 3/8

DOT Swivel Branch Tee Male Brass 3/8 x 3/8 x 3/8"

Item#: 27218
DOT Swivel Elbow Male 90° Brass 3/8 x 1/2-14, DOT Air Brake Push to Connect Swivel Elbow, 90°, Male, Brass, 3/8 x 1/2-14

DOT Swivel Elbow Male 90° Brass 1/2 x 1/4-18

Item#: 28980
DOT Branch Tee Male Brass 1/4 x 1/4 x 1/8-27, DOT Air Brake Push to Connect Branch Tee, Male, Brass, 1/4 x 1/4 x 1/8-27

DOT Branch Tee Male Brass 3/8 x 3/8 x 3/8-18

Item#: 28990
DOT Elbow Male 90° Brass 1/4 x 1/4-18, DOT Air Brake Push to Connect Elbow, 90°, Male, Brass, 1/4 x 1/4-18, Tube x Pipe

DOT Elbow Male 90° Brass 3/8 x 1/8-27

Item#: 27186
DOT Swivel Branch Tee Male Brass 3/8 x 3/8 x 3/8

DOT Swivel Branch Tee Male Brass 3/8 x 3/8 x 3/8"

Item#: 27218
Face Seal O-Ring Buna-N 0.301 x 0.07

Face Seal O-Ring Buna-N 0.489 x 0.07"

Item#: 52094
KH Series Crimp-On Elbow Flare 90° 1/4

KH Series Crimp-On Elbow Flare 90° 1/2" x 3/4-16

Item#: 88382KH
Weatherhead H280 Hydraulic Hose Rubber 0.53

Weatherhead H280 Hydraulic Hose Rubber 0.81" x 50'

Item#: 50799 08
Constant Torque Hose Clamp SS 4-1/4 to 5-1/8

Constant Torque Hose Clamp SS 2-1/4 to 3-1/8"

Item#: 97564
Z Series Crimp-On Hose End 1/2

Z Series Crimp-On Hose End 1/2 x 3/4-16"

Item#: 16615
Ball Check Grease Fitting 90°, Ball Check Grease Fitting, 90°, Hardened Steel, 1/8

Ball Check Grease Fitting 90°

Item#: 6203
No product placeholder

HT4OF4

Item#: 1593499
Hydraulic Quick Connect Coupler 1/4

Hydraulic Quick Connect Coupler 3/8" x 3/8-18

Item#: 29970
Hydraulic Quick Connect Coupler 1/4

Hydraulic Quick Connect Coupler 1/4" x 1/4-18

Item#: 29969
SAE Flat Washer Thru-Hardened Steel 5/8

SAE Flat Washer Thru-Hardened Steel 5/8"

Item#: 88441
Interchangeable Hex Bit Set 20Pc Torx, 20 Pc, Interchangeable Torx Quick Release Hex Bit Set

Interchangeable Hex Bit Set 20Pc Torx

Item#: DY89310522
Superbutt Connector 16 to 14 AWG Blue, Superbutt Connector, Extended Barrel, Blue, 16 to 14 AWG, 1.075

Superbutt Connector 16 to 14 AWG Blue

Item#: 94728

Product Description

Keep hydraulic connections clear in dirty conditions with this Quick Connect Nipple. The flat face design wipes clean easily and operates successfully in applications involving high pressure pulses. Heavy-duty locking sleeve provides greater strength and prevents accidental disconnection, while non-spill design guards against fluid loss during connection and disconnection. Ideal for use in agriculture, construction, mobile equipment, general industrial, mining and nuclear equipment. To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.
• Zinc-plated steel body
• PTFE and nitrile rubber seals
• Conforms to ISO 16028 Standards
• Operating temperature range: –4°F to +212°F (–20°C to +100°C)
• Meets or exceeds HTMA requirements
Dixon: HT-Series
To couple, wipe the mating faces clean and push the two halves together until they click shut. Twist the sleeve to lock the coupling. To release, align the notched sleeve with the ball and pull back – the coupling springs apart.

Technical Specifications

Item#: 29974
Hydraulic / Pneumatic Hydraulic
Description Quick Coupling
Type Nipple
Style ISO 16028
Standards ISO 16028
Body Size 6.3mm (1/4")
Thread Size 1/4-18
Thread Style Female NPTF
Burst Pressure 17,400 PSI
Seal Material Nitrile
Material Steel
Flow 3.2 gal/min
Length 1.89 "
Temperature Range -40 to 212 F
Working Pressure 4,350 PSI
Hex Size 0.87 "
Maximum Diameter 0.94 "
Coupled Length 3.35 "
Tip Diameter 0.636 "
UNSPSC #: 27121701
TAA Compliant: Yes
Weight: 0.21 lb
