Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 6mm x 1/4", Tube x Male BSPT, 150 PSI Working Pressure
(Pack of 5)

Item#: 98202

Lawson Products

Designed for pneumatic installations and conveyance of inert gases. Resin series is available in both fractional inch and metric tubes. These lightweight composite fittings are all for quick, tool free installation and reliable delivery. Compatible with both polyurethane and nylon tubing.
• Working Temperature: 32°F – 140°F
• Working Pressure: 150 PSI
• Suitable Fluids: Compressed air/inert gases
• Vacuum Compatibility: 29.5” HG
Construction:
• Body Material: Nickel plated brass with resin body material constructed of polybutylene terephthalate (PBT)
• Gripping Ring: 301 stainless steel
• Release Ring: Acetal plastic
• O-Ring: NBR (Buna-N)
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.

Read More
Check Availability

Catalog page#: 9-30

Frequently Bought Together

Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/8 x 1/8

Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/8 x 1/8"

Item#: 86756
Push-to-Connect Plug, Nickel-Plated Brass/PBT Resin, 1/8

Push-to-Connect Plug, Nickel-Plated Brass/PBT Resin, 1/4"

Item#: 54437
Push-to-Connect Union, Nickel-Plated Brass/PBT Resin, 1/4 x 1/4

Push-to-Connect Union, Nickel-Plated Brass/PBT Resin, 1/4 x 1/4"

Item#: 86781
Brass male pipe push-on elbow fitting, Male brass push-on 90 degree elbow rigid 1/4 inch x 1/8 inch MPT fitting

Push-to-Connect Elbow, Nickel-Plated Brass, 1/8 x 5/16"

Item#: DY41726952
Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 5/32

Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 5/32" x 10-32

Item#: 62201
Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/2 x 3/8

Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/2 x 3/8"

Item#: 86813
Push-to-Connect Connector, Nickel-Plated Brass/PBT Resin, 16mm x 1/2

Push-to-Connect Connector, Nickel-Plated Brass/PBT Resin, 5/32"x M5

Item#: 17894
Push-to-Connect Unequal Union, Nickel-Plated Brass/PBT Resin, 6 x 8mm, Tube x Tube, 150 PSI Working Pressure

Push-to-Connect Unequal Union, Nickel-Plated Brass/PBT Resin, 5/32" x 6mm

Item#: 1200096
Push-to-Connect Tee, Nickel-Plated Brass/PBT Resin, 6 x 6 x 6mm, Tube x Tube x Tube, 150 PSI Working Pressure

Push-to-Connect Tee, Nickel-Plated Brass/PBT Resin, 6 x 6 x 6mm

Item#: 98215
Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 1/2-14 x 1/4-18

Item#: 5286
Hex Head Plug Brass 1/2-14 Male NPT, Hex Head Plug, Brass, 1/2-14 Male NPT, 1200PSI

Hex Head Plug Brass 3/8-18 Male NPT

Item#: 5364
Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 3/8-18 x 1/4-18

Item#: 5284
Pipe Bushing Brass 1/2-14 x 1/8-27, Pipe Bushing, Brass, 1/2-14 x 1/8-27, Male NPT x Female NPT, 1200PSI

Pipe Bushing Brass 1/2-14 x 3/8-18

Item#: 5287
Miniature Clamp SS 7/32 to 5/8

Miniature Clamp SS 7/32 to 5/8"

Item#: 86738
DOT Union Nylon 1/4 x 1/4

DOT Union Nylon 1/4 x 1/4"

Item#: 91819
Push-to-Connect Union, Nickel-Plated Brass/PBT Resin, 1/4 x 1/4

Push-to-Connect Union, Nickel-Plated Brass/PBT Resin, 1/4 x 1/4"

Item#: 86781
Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/4 x 1/8

Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/4 x 1/8"

Item#: 86760
Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/4 x 1/4

Push-to-Connect Elbow, Nickel-Plated Brass/PBT Resin, 1/4 x 1/4"

Item#: 86761
Nylon Cable Tie 15.25

Nylon Cable Tie 15.25" Black

Item#: 94613
Nylon Cable Tie 15.25

Nylon Cable Tie 11.75" Black

Item#: 94611
Nylon Cable Tie 15.25

Nylon Cable Tie 15.5" Black

Item#: 94612

Product Description

Designed for pneumatic installations and conveyance of inert gases. Resin series is available in both fractional inch and metric tubes. These lightweight composite fittings are all for quick, tool free installation and reliable delivery. Compatible with both polyurethane and nylon tubing.
• Working Temperature: 32°F – 140°F
• Working Pressure: 150 PSI
• Suitable Fluids: Compressed air/inert gases
• Vacuum Compatibility: 29.5” HG
Construction:
• Body Material: Nickel plated brass with resin body material constructed of polybutylene terephthalate (PBT)
• Gripping Ring: 301 stainless steel
• Release Ring: Acetal plastic
• O-Ring: NBR (Buna-N)
CAUTION: These fitting systems are not D.O.T. approved. Do not use for air brake connections.

Technical Specifications

Item#: 98202
Configuration Male Elbow
Tube Size 6 mm
Thread Size R1/4 "
Thread Style BSPT
Material Nickel-Plated Brass/PBT Resin
Wrench Size 14 mm
Working Pressure 150 PSI
Temperature Range 32 to 140 °F
UNSPSC #: 40183100
TAA Compliant: Yes
Weight: 0.17 lb
