3/16" X 4" Gray Thermapod Heat Shrink Tube
(Pack of
1.0)
Thermal Shrinkable Wire Protection
Double Layer . . . Double Protection
• Thermapod™ is an easy-to-use heat-shrink system that protects wire connections from 4/0 cable down to 22-gauge wire. Almost any heat source will convert the Thermapod™ into a moisture-resistant, tailor-fit covering for wire connection
• Combines a sealant inner layer and a tough, abrasion-resistant outer cover
• The shrinking outer layer forces the liquid inner layer into the crevices and spaces of the wires or cable for a moisture-resistant, perfect fit
• When the two layers cool, they become a semi rigid, protective “pod” that seals the wiring from the environment
• Improved encapsuliation and strain damage from flexing
• Temperature Rating: -67°F to +230°F/ -55°C to +110°C
• Shrink Temperature: 275°F/135°C
Frequently Bought Together
180-degree Wide Beam Head Light with Side Light
Couldn't load pickup availability
Stepdown Butt Connector 22 to 18/16 to 14 AWG
Couldn't load pickup availability
Superbutt Connector 22 to 18 AWG Red
Couldn't load pickup availability
Heat Shrink Tubing 12 to 6 AWG Black
Couldn't load pickup availability
Heat Shrink Tubing 30 to 18 AWG Black
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 16 to 14 AWG Black
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Red
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Clear
Couldn't load pickup availability
Heat Shrink Tubing 18 to 12 AWG Clear
Couldn't load pickup availability
Tru-Shrink Heat Shrink Tubing 20 to 18 AWG Red
Couldn't load pickup availability
Heat Shrink Tubing 20 to 14 AWG Black
Couldn't load pickup availability
Product Description
Thermal Shrinkable Wire ProtectionDouble Layer . . . Double Protection
• Thermapod™ is an easy-to-use heat-shrink system that protects wire connections from 4/0 cable down to 22-gauge wire. Almost any heat source will convert the Thermapod™ into a moisture-resistant, tailor-fit covering for wire connection
• Combines a sealant inner layer and a tough, abrasion-resistant outer cover
• The shrinking outer layer forces the liquid inner layer into the crevices and spaces of the wires or cable for a moisture-resistant, perfect fit
• When the two layers cool, they become a semi rigid, protective “pod” that seals the wiring from the environment
• Improved encapsuliation and strain damage from flexing
• Temperature Rating: -67°F to +230°F/ -55°C to +110°C
• Shrink Temperature: 275°F/135°C
Technical Specifications
| Item#: | DY21860953 |
|---|---|
| Type | Pre-Cut |
| Style | Dual Wall |
| Wire Gauge Coverage | 20-18 AWG |
| Diameter | 3/16 " |
| Length | 4 ft |
| Color | Gray |
| I.D. Before Shrinkage | 0.187 " |
| I.D. After Shrinkage | 0.06 " |
| Shrink Ratio | 3:1 |
| Dielectric Strength | 500 V/mil |
| Temperature Rating | -67°F to 230°F/ -55°C to 110°C |
| Shrink Temperature | 275°F/135°C |
| Tensile Strength | 1,500 PSI |
| Approvals | SAE-AMS-DTL - 23053/4, CL-1 |
| Description | Thermapod Heat Shrink Tubing Gray 3/16 x 4' |
| UNSPSC #: | 39121723 |
| TAA Compliant: | Yes |
| Weight: | 0.56 lb |
