Cryo-Drap 7/16"-14 Drill & Tap Combo, 135o Split Point, W/Flats, 3/4" Max Material Thickness
(Pack of
1)
SKU:DY80244422 Item#: DY80244422
Combine the Cryobit® drill tip with the Cryotap® threads. Maximize performance with the patented Cryophase treatment. Deliver the ultimate drill tap Cryo-Drap.
• Durable - Cryophase™ process increases life, durability and flexibility
• Reduces Inventory - No need to find the matching drill bit to use with the common tap
• Fast and Easy - Transforms a two-step "drill and tap process" into a seamless one-step process
• No need to hunt and find a "drill and tap chart" every time you tap a through hole
• Perfect addition to three-drawer tap cabinets
Specifications
• Tip Design: 135° split point
• Tap Tolerance: H3
• Material: High Speed Steel
• Surface: Black and gold oxide
• Heat Treatment: Austempered twice
• Cryophase™: Thermal cycling cryogenic treatment
Note: Use only for tapping thru holes. Exceeding max material thickness will break the tool. Always lubricate before use.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Couldn't load pickup availability
Catalog page#: LE-80
Frequently Bought Together
HSS Combination Drill-Tap M8
Couldn't load pickup availability
Cryo-Drap #10-32 Drill & Tap Combo, 135o Split Point, W/Flats
Couldn't load pickup availability
Cryo-Drap #10-24 Drill & Tap Combo, 135o Split Point, W/Flats
Couldn't load pickup availability
Jobber Length Drill Bit HSS 7/32"
Couldn't load pickup availability
Jobber Length Drill Bit HSS 9/64"
Couldn't load pickup availability
Abrasive Hand Pad All Purpose 6 x 9"
Couldn't load pickup availability
7" Auto-Adjust Pliers
Couldn't load pickup availability
18" Locking Smooth Operator Clamp
Couldn't load pickup availability
Extendable Handle Ratchet 3/8 Drive
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Stepdown Butt Connector 22 to 18/16 to 14 AWG
Couldn't load pickup availability
180-degree Wide Beam Head Light with Side Light
Couldn't load pickup availability
4-Flute HSS Taper Hand Tap M6 x 1
Couldn't load pickup availability
Cryo-Drap 1/2"-13 Drill & Tap Combo, 135o Split Point, W/Flats
Couldn't load pickup availability
4-Flute HSS Bottoming Hand Tap M10 x 1.5
Couldn't load pickup availability
Universal Socket Set, Metric, 3/8" Drive, 12pc
Couldn't load pickup availability
3" Pneumatic Cut-Off Tool
Couldn't load pickup availability
1/4" - 3/4" Cryonitride Spiral Fluted Step Drill - 3/8" Shank
Couldn't load pickup availability
Product Description
Combine the Cryobit® drill tip with the Cryotap® threads. Maximize performance with the patented Cryophase treatment. Deliver the ultimate drill tap Cryo-Drap.• Durable - Cryophase™ process increases life, durability and flexibility
• Reduces Inventory - No need to find the matching drill bit to use with the common tap
• Fast and Easy - Transforms a two-step "drill and tap process" into a seamless one-step process
• No need to hunt and find a "drill and tap chart" every time you tap a through hole
• Perfect addition to three-drawer tap cabinets
Specifications
• Tip Design: 135° split point
• Tap Tolerance: H3
• Material: High Speed Steel
• Surface: Black and gold oxide
• Heat Treatment: Austempered twice
• Cryophase™: Thermal cycling cryogenic treatment
Note: Use only for tapping thru holes. Exceeding max material thickness will break the tool. Always lubricate before use.
CAUTION: Any cutting tool may break or shatter under improper use. Government regulations require use of safety glasses and other appropriate safety equipment at all times in the vicinity of use.
Technical Specifications
| Item#: | DY80244422 |
|---|---|
| Type | Combination Drill Tap |
| Point | 135° Split |
| Diameter | 7/16 " |
| Pitch | 14 |
| Tap Length | 0.8800 " |
| Material Thickness | 3/4 " |
| Overall Length | 4.16 " |
| UNSPSC #: | 23241615 |
| TAA Compliant: | No |
| Weight: | 0.095 lb |
