Home Bolts Hex Flange Locking Screw Grade 5 1/2-13 x 1-3/4"
Bolts

Hex Flange Locking Screw, Grade 5, Steel, Zinc Finish, Coarse Thread, 3/4" Across Flats, 1/2-13 x 1-3/4"
(Pack of 25)

Item#: 54863

Lawson Products

• Case-hardened
• Serrations under head provide locking effect
• Zinc-plated
• 120,000 PSI tensile strength
• Popular for automotive applications
Minimum Threaded Length –
Up to 6" Long: (2 x Diameter) + 1/4"
Over 6" Long: (2 x Diameter) + 1/2"

Read More
Check Availability
Usually Ships: Today
While Supplies Last

Catalog page#: 3-64

Frequently Bought Together


Hex Cap Screw Grade 8 Alloy Steel 5/16-18 x 1-1/4"

Item#: 618

Hex Cap Screw Property Class 10.9 M6-1 x 15mm

Item#: 4266

Hex Cap Screw Grade 8 Alloy Steel 5/16-18 x 1-1/2"

Item#: 619

Hex Nut Grade 5 Steel 5/16-18

Item#: FA95678

Hex Nut Grade 8 Steel 1/4-20

Item#: FA68400

Hex Nut Grade 5 Steel 5/8-11

Item#: FA95683

Hex Flange Bolt Grade 8 1/2-13 x 1-1/2"

Item#: 86398

Hex Flange Bolt Grade 10.9 M8-1.25 x 45mm

Item#: 59734

Hex Flange Bolt Grade 10.9 M10-1.25 x 35mm

Item#: 28694

Hex Cap Screw Grade 8 3/8-16 x 1"

Item#: FA68032

IFI 100/107 Top Locknut Grade C 1/4-20

Item#: 80927

Self-Drilling Screw Hex Head #10-16 x 1"

Item#: 84932

Hex Nut Grade 8 Alloy Steel 1/2-13

Item#: A104

SAE J995C Locknut with Nylon Insert Grade 8 5/8-11

Item#: 53985

Interchangeable Hex Bit Set 20Pc Torx

Item#: DY89310522

12Pc SAE 12Pt Cross-Torque Wrench Set

Item#: DY89310261

Swivel Head Ratchet 1/4 Drive

Item#: DY89310009

Z-Flex 2" Dia., 60 Grit, Roll Lock Mount, Zirconia Alumina

Item#: DY87802064

12Pc SAE 12Pt Cross-Torque Wrench Set

Item#: DY89310261

Swivel Head Ratchet 1/4 Drive

Item#: DY89310009

Z-Flex 2" Dia., 60 Grit, Roll Lock Mount, Zirconia Alumina

Item#: DY87802064

Product Description

• Case-hardened
• Serrations under head provide locking effect
• Zinc-plated
• 120,000 PSI tensile strength
• Popular for automotive applications
Minimum Threaded Length –
Up to 6" Long: (2 x Diameter) + 1/4"
Over 6" Long: (2 x Diameter) + 1/2"

Technical Specifications

Item#: 54863
Type Hex Flange Bolt
Diameter 1/2 "
Thread Pitch 13
Thread Coarse
Length 1-3/4 "
Finish Bright Zinc
Material Carbon Steel
Grade 5
Head Style Serrated Hex Flange
Size 1/2X1-3/4 "
Across Flats 3/4 "
Tensile Strength 120,000 PSI
UNSPSC #: 31161620
TAA Compliant: No
Weight: 3.7 lb
