Reusable Posi-Lock Butt Connector, 6-8 AWG Wire, Green
(Pack of
5)
• Splice two or more wires together anywhere, without soldering, crimping or heating
• Strip the wire ends, insert the wire into the Posi-Lock and hand tighten
• Disconnect and reconnect repeatedly without impairing connection integrity
• These wire locks can be used over and over with consistent, positive results.
• Maximum Temperature Rating: Continuous 220˚F/105˚C Intermittent 250˚C/482˚F
Couldn't load pickup availability
Catalog page#: LE-146
Frequently Bought Together
Cable Tie 7.31" Black
Couldn't load pickup availability
Stepdown Butt Connector 24 to 22/22 to 18 AWG
Couldn't load pickup availability
Extension Cord Tri-Tap Adapter 15A 125V
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/8"
Couldn't load pickup availability
Butt Connector 26 to 22 AWG
Couldn't load pickup availability
Ring Tongue Terminal 12 to 10 AWG Yellow
Couldn't load pickup availability
Ring Tongue Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Term-A-Nut Pigtail Connector 18 to 12 AWG
Couldn't load pickup availability
Wire Nut Twister 22-12 AWG Tan
Couldn't load pickup availability
Watertight Wire Nuts 4 - 8 Gauge/2 - 12 Gauge Yellow
Couldn't load pickup availability
Reusable Posi-Lock Butt Connector 14-16 AWG Wire Blue
Couldn't load pickup availability
Wire Nut Posi-Twist 24-14 AWG
Couldn't load pickup availability
Reusable Posi-Lock Butt Connector 10-12 AWG Wire Yellow
Couldn't load pickup availability
Product Description
• Splice two or more wires together anywhere, without soldering, crimping or heating• Strip the wire ends, insert the wire into the Posi-Lock and hand tighten
• Disconnect and reconnect repeatedly without impairing connection integrity
• These wire locks can be used over and over with consistent, positive results.
• Maximum Temperature Rating: Continuous 220˚F/105˚C Intermittent 250˚C/482˚F
Technical Specifications
| Item#: | DY20060810 |
|---|---|
| Type | Butt Connector |
| Wire Gauge | 8-6 AWG |
| Voltage Rating | 600 V |
| Color | Green |
| Maximum Temperature Rating | Continuous 220˚F/ 105˚C Intermittent 250˚C/482˚F |
| Approvals | UL 486C and SAE J1211 |
| Description | Green Reusable Posi-Lock Butt Connector, 8-6 AWG |
| Style | Posi-Lock™ Connectors |
| UNSPSC #: | 39121409 |
| TAA Compliant: | No |
| Weight: | 0.095 lb |
