Round Pin Anchor Shackle, 1-1/4", 28,000 lb WLL
(Pack of
1.0)
Ensure secure and efficient load handling with the Round Pin Anchor Shackle. Designed for trucking and transportation professionals, this shackle is perfect for tie-down, towing, and suspension applications where the load is applied in-line. Made from durable galvanized carbon steel, it’s built to last while resisting corrosion in tough conditions. The round pin, secured with a cotter pin, allows for quick assembly and disassembly, saving valuable time on the job. Ideal for applications involving torque or twisting actions, the Round Pin Anchor Shackle delivers reliability when you need it most.
• Working Load Limit and traceability codes shown as permanent marking on body and pin
• All shackles meet or exceed Federal Specification RRC-271F, Type IVA, Grade A, Class 1
• Unsatisfactory in applications where the pin is subjected to an axial load
• Design factor 5:1
CAUTION: Do not exceed working load limits.
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog page#: 15-22
Frequently Bought Together
Eyebolt, Machinery, Stainless Steel, 5/16" x 1-1/8"
Couldn't load pickup availability
Shoulder Eyebolt, Machinery, Self-Colored, 7/16" x 1-3/8"
Couldn't load pickup availability
Shoulder Eyebolt, Machinery, Galvanized, M18 x 2.5 x 51
Couldn't load pickup availability
Shelf Bin, Blue, 11-5/8" x 6-5/8" x 4"
Couldn't load pickup availability
AkroBin®, Blue, 10-7/8" x 11" x 5"
Couldn't load pickup availability
Double Clevis (Mid-Link), 3/8", 6,600 lb WLL
Couldn't load pickup availability
Screw Pin Anchor Shackle, 1-1/4", 28,000 lb WLL
Couldn't load pickup availability
Bolt, Nut and Cotter Anchor Shackle, 7/8", 17,000 lb WLL
Couldn't load pickup availability
Bolt, Nut and Cotter Anchor Shackle, 7/8", 13,000 lb WLL
Couldn't load pickup availability
Self-Drilling Screw Hex Head #10-16 x 3/4"
Couldn't load pickup availability
Non-Chlorinated Brake Parts Cleaner 14oz
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/2-13
Couldn't load pickup availability
Product Description
Ensure secure and efficient load handling with the Round Pin Anchor Shackle. Designed for trucking and transportation professionals, this shackle is perfect for tie-down, towing, and suspension applications where the load is applied in-line. Made from durable galvanized carbon steel, it’s built to last while resisting corrosion in tough conditions. The round pin, secured with a cotter pin, allows for quick assembly and disassembly, saving valuable time on the job. Ideal for applications involving torque or twisting actions, the Round Pin Anchor Shackle delivers reliability when you need it most.• Working Load Limit and traceability codes shown as permanent marking on body and pin
• All shackles meet or exceed Federal Specification RRC-271F, Type IVA, Grade A, Class 1
• Unsatisfactory in applications where the pin is subjected to an axial load
• Design factor 5:1
CAUTION: Do not exceed working load limits.
Technical Specifications
| Item#: | 1429908 |
|---|---|
| Type | Anchor Shackle |
| Style | Round Pin |
| Body Material | Carbon Steel |
| Finish | Orange Powder Coated |
| Size | 1-1/4 " |
| Working Load Limit | 28,000 lb |
| Pin Diameter | 1-3/8 " |
| Pin Material | Alloy Steel |
| Width Between Eyes | 2-1/32 " |
| Bow Width | 2-7/8 " |
| Depth | 4-11/16 " |
| UNSPSC #: | 31162803 |
| TAA Compliant: | Yes |
| Weight: | 10.06 lb |
