Turnbuckle, Hook and Eye, Galvanized, 1/2" x 6"
(Pack of
1.0)
• Turnbuckles can be used to apply tension to wire rope or cable
• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class F
• Apply load to the center of end attachment eyes and bowl of hooks. Do not tip load hooks or side load eyes
CAUTION: Do not exceed working load limits.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog Page#: 15-27
Frequently Bought Together
Eyebolt, Machinery, Self-Colored, 5/16" x 1-1/8"
Couldn't load pickup availability
Turned Eyebolt, Stainless Steel, 1/2" x 4"
Couldn't load pickup availability
Eye Bolts, Machinery, 5/16 x 1-1/8"
Couldn't load pickup availability
Wire Rope, Steel, Nylon Coated, 7x19, 1/8", 2,000 lbs Breaking Strengt
Couldn't load pickup availability
Wire Rope, Steel, Bare, 7x19, 5/16", 9,800 lbs Breaking Strength
Couldn't load pickup availability
Wire Rope, Steel, Bare, 7x19, 3/16", 4,200 lbs Breaking Strength
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 5/8-11
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M8
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/8"
Couldn't load pickup availability
Turnbuckle, Stainless Steel, Hook and Eye, 1/4" x 3" Take Up
Couldn't load pickup availability
Turnbuckle, Stainless Steel, Jaw and Jaw, 5/16" x 4.50" Take Up
Couldn't load pickup availability
Turnbuckle, Stainless Steel, Jaw and Jaw, 1/2" x 6.00" Take Up
Couldn't load pickup availability
Product Description
• Turnbuckles can be used to apply tension to wire rope or cable• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class F
• Apply load to the center of end attachment eyes and bowl of hooks. Do not tip load hooks or side load eyes
CAUTION: Do not exceed working load limits.
Technical Specifications
| Item#: | 1442154 |
|---|---|
| Type | Hook and Eye |
| Diameter | 1/2 " |
| Closed Length | 13-5/8 " |
| Working Load Limit | 1,500 lb |
| Material | Forged Steel |
| Finish | Galvanized |
| UNSPSC #: | 24101611 |
| TAA Compliant: | Yes |
| Weight: | 1.67 lb |
