Turnbuckle, Hook and Eye, Galvanized, 5/16" x 4-1/2"
(Pack of
1.0)
• Turnbuckles can be used to apply tension to wire rope or cable
• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class F
• Apply load to the center of end attachment eyes and bowl of hooks. Do not tip load hooks or side load eyes
CAUTION: Do not exceed working load limits.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog Page#: 15-27
Frequently Bought Together
Turned Eyebolt, Zinc-Plated, 3/8" x 2"
Couldn't load pickup availability
Eyebolt, With Nut, Galvanized, 1/2" x 4-1/2"
Couldn't load pickup availability
Turned Eyebolt, Zinc-Plated, 5/16" x 3"
Couldn't load pickup availability
Screw Pin Anchor Shackle, 5/16", 1,500 lb WLL
Couldn't load pickup availability
Tarp Strap Epdm Rubber with Hooks 35" Long
Couldn't load pickup availability
Drum Handling Sling Vertical Drums 36" Diameter
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Nylon Cable Tie 4" Black
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Clear
Couldn't load pickup availability
Turnbuckle – Midget, Hook and Hook, Malleable, #26 3/8 - 16
Couldn't load pickup availability
Turnbuckle, Stainless Steel, Eye and Eye, 5/8" x 8" Take Up
Couldn't load pickup availability
Turnbuckles Eye and Eye 1/2" x 9" Takeup
Couldn't load pickup availability
Product Description
• Turnbuckles can be used to apply tension to wire rope or cable• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class F
• Apply load to the center of end attachment eyes and bowl of hooks. Do not tip load hooks or side load eyes
CAUTION: Do not exceed working load limits.
Technical Specifications
| Item#: | 1442447 |
|---|---|
| Type | Hook and Eye |
| Diameter | 5/16 " |
| Closed Length | 9-1/4 " |
| Working Load Limit | 700 lb |
| Material | Forged Steel |
| Finish | Galvanized |
| UNSPSC #: | 24101611 |
| TAA Compliant: | Yes |
| Weight: | 0.39 lb |
