Watertight Wire Nuts, 4 - 8 Gauge/2 - 12 Gauge, Yellow
(Pack of
25)
SKU:DY20720040 Item#: DY20720040
• Moisture and corrosion resistant wire connections
• Sealant provides 500 volts of insulation for every 1 mil of thickness
• Can be used in watertight boxes to further protect against condensation, ice formation, fumes and flooding
• The unique resin outer shell and modified silicone fill provide excellent protection against most chemical environments including ammonia, acids, salts and waste material
• Great in damp and wet areas, can be submersed but not continuously
Couldn't load pickup availability
Catalog page#: LE-146
Frequently Bought Together
MINI Fuse 15A Blue
Couldn't load pickup availability
Super 33+ Series Vinyl Electrical Tape Black 3/4"
Couldn't load pickup availability
Stepdown Butt Connector 24 to 22/22 to 18 AWG
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/2-13
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
Male Quick Slide Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Spade Terminal 16 to 14 AWG Blue
Couldn't load pickup availability
Wire Connector 22 to 14 AWG Orange
Couldn't load pickup availability
T/R Plus Wire Connector 22 to 8 AWG
Couldn't load pickup availability
Waterproof Wire Connector 22 to 12 AWG
Couldn't load pickup availability
Fork Pigtail Connector 18 to 12 AWG Green
Couldn't load pickup availability
Wire Connector-Hi-Temperature-18-10 AWG
Couldn't load pickup availability
Term-A-Nut Terminal Connector 22 to 12 AWG
Couldn't load pickup availability
Wire Connector Assortment 410Pcs
Couldn't load pickup availability
Product Description
• Moisture and corrosion resistant wire connections• Sealant provides 500 volts of insulation for every 1 mil of thickness
• Can be used in watertight boxes to further protect against condensation, ice formation, fumes and flooding
• The unique resin outer shell and modified silicone fill provide excellent protection against most chemical environments including ammonia, acids, salts and waste material
• Great in damp and wet areas, can be submersed but not continuously
Technical Specifications
| Item#: | DY20720040 |
|---|---|
| Type | Wire Nut |
| Wire Gauge | 18 (4 Wire) to 12 (2 Wire) AWG |
| Voltage Rating | 600V Maximum for Building Wire 1,000V Maximum in Signs and Fixtures |
| Color | Yellow |
| Temperature Range | 221 °F |
| Celcius Temperature Range | 105 C |
| Length | 1-9/16 " |
| O.D. | 11/16 " |
| Approvals | CSA C22.2 |
| Style | Water Tight Wire Nuts |
| UNSPSC #: | 39121409 |
| TAA Compliant: | Yes |
| Weight: | 0.28 lb |
