Weatherhead H280 Hydraulic Hose, 1/4" ID, 0.53" OD, 50' Length, 6500PSI, Vinyl Nitrile, 2-Steel Braided, SAE 100R16S
(Pack of
50)
SKU:50799 04 Item#: 50799 04
• Dura-Tuff premium abrasion resistant hose cover offers 8x greater abrasion resistance than industry standard
• Agency Ratings: SAE 100R17, SAE 100R1, EN 857 1SC
• Fittings Certified: Z-Series
• Agency Approval: MSHA, ABS, USCG and DNV
• Construction:
– Inner Tube: Nitrile
– Reinforcement: Two steel braids
– Cover: Dura-Tuff Premium Abrasion
• Temperature Range:
– Petroleum and Water based fluids: –50°F to +260°F (–46°C to +127°C)
• Application Notes: Hydraulic systems service with petroleum and water-based fluids, for general use
Couldn't load pickup availability
Catalog page#: 8-11
Frequently Bought Together
Z Series Crimp-On Hose End 3/4" x 1-3/16-12
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/2" x 1-5/16-12
Couldn't load pickup availability
Hydraulic Quick Connect Nipple 3/4" x 1-11-1/2
Couldn't load pickup availability
Hydraulic Quick Connect Coupler 3/4" x 1-11-1/2
Couldn't load pickup availability
Z Series Crimp-On Hose End 3/4" x 1-3/16-12
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/2" x 1-5/16-12
Couldn't load pickup availability
SAE R16S Hydraulic Hose Rubber 0.67" x 250'
Couldn't load pickup availability
Weatherhead H430 Hydraulic Hose 1-7/32" x 50'
Couldn't load pickup availability
Weatherhead H280 Hydraulic Hose 0.69" x 250'
Couldn't load pickup availability
Crimp-On Hose Coupling 1/2" x 7/8-14
Couldn't load pickup availability
Hydraulic Cap Nut, 7/8-14"(10) Female JIC SAE 37 Degree Flare
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/2" x 13/16-16
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 9/16 to 1-1/16"
Couldn't load pickup availability
Hose Clamp 301 SS 9/16 to 1-1/4"
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/8-27
Couldn't load pickup availability
SAE R16S Hydraulic Hose Rubber 0.67" x 250'
Couldn't load pickup availability
Weatherhead H430 Hydraulic Hose 1-7/32" x 50'
Couldn't load pickup availability
Weatherhead H280 Hydraulic Hose 0.69" x 250'
Couldn't load pickup availability
Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/4-20
Couldn't load pickup availability
IFI 100/107 Top Locknut Grade C 5/8-11
Couldn't load pickup availability
Product Description
• Dura-Tuff premium abrasion resistant hose cover offers 8x greater abrasion resistance than industry standard• Agency Ratings: SAE 100R17, SAE 100R1, EN 857 1SC
• Fittings Certified: Z-Series
• Agency Approval: MSHA, ABS, USCG and DNV
• Construction:
– Inner Tube: Nitrile
– Reinforcement: Two steel braids
– Cover: Dura-Tuff Premium Abrasion
• Temperature Range:
– Petroleum and Water based fluids: –50°F to +260°F (–46°C to +127°C)
• Application Notes: Hydraulic systems service with petroleum and water-based fluids, for general use
Technical Specifications
| Item#: | 50799 04 |
|---|---|
| Industrial / Hydraulic | Hydraulic |
| Type | Rubber - Steel Braided |
| Category / Performance | High Pressure |
| Industry Rating 1 | SAE 100R17 |
| Industry Rating 2 | EN 857 1SC |
| Industry Rating | MSHA, ABS, USCG and DNV |
| Manufacturer Series Number | H280 |
| Manufacturer Series Name | DURA-TUFF |
| I.D. | 1/4 (-4) " |
| Hose O.D. | 0.53 " |
| Working Pressure | 6,500 PSI |
| Burst Pressure | 26,000 PSI |
| Fitting Series | Z Series |
| Bend Radius | 2 " |
| Inner Tube Material | Nitrile |
| Hose Reinforcement | 2 Steel Braids |
| Hose Cover Material | Nitrile |
| Temperature | High |
| Material | Hydraulic Oil |
| Applications | Hydraulic - Constant Flow |
| Temperature Range | Petroleum based fluids -50F to +260F, Water based fluids -50F to +260 F |
| UNSPSC #: | 40142020 |
| TAA Compliant: | No |
| Weight: | 11.75 lb |
