601 Xl Flux Core All Steel Mig Wire Duel Sheilded Flux Gas 100% Co2 Or 75%Ar 25%Co2 Elongation 25%Tensile 115000 Low Hydrogen Flux
(Pack of
33)
• Designed for Welding All Steels – Manganese, stainless, AR plate, high-carbon and dissimilar combinations
• Superior Welding Speed – Three times faster than stick welding and over 1-3/4 times faster than solid wires
• High Recovery Rate – Over 90% deposition efficiency, low heat input means less distortion and better tolerance control
• All-position self-lifting slag
• Tensile Strength: 95,000 PSI/655 Mpa
• Yield Strength: 76,000 PSI/524 Mpa
• Service Temperature: Up to 600°F/316°C
• Elongation: 37%
• Corrosion Resistance: Excellent
• Hardness: 90Rb
• Current: DCEP (DC+)
• Gas: 75% Ar/25% CO2; or 100% CO2
Couldn't load pickup availability
Catalog page#: LE-130
Frequently Bought Together
333 Dissimilar Steel TIG Wire 0.035"
Couldn't load pickup availability
333 Dissimilar Steel Stick Rod Electrode 3/32"
Couldn't load pickup availability
333 Dissimilar Steel Stick Rod Electrode 5/32"
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Clear
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
High Solids Paints Gloss Black
Couldn't load pickup availability
333 Dissimilar Steel TIG Wire 1/16"
Couldn't load pickup availability
ER4043 Aluminum MIG Welding Wire 0.035"
Couldn't load pickup availability
24A-62 MIG Welding Nozzle 5/8"
Couldn't load pickup availability
163 Arc-Cut Synthetic Carbon Arc Electrode
Couldn't load pickup availability
510 Aluminum TIG Wire 1/8"
Couldn't load pickup availability
333 Dissimilar Steel TIG Wire 3/32"
Couldn't load pickup availability
Product Description
• Designed for Welding All Steels – Manganese, stainless, AR plate, high-carbon and dissimilar combinations• Superior Welding Speed – Three times faster than stick welding and over 1-3/4 times faster than solid wires
• High Recovery Rate – Over 90% deposition efficiency, low heat input means less distortion and better tolerance control
• All-position self-lifting slag
• Tensile Strength: 95,000 PSI/655 Mpa
• Yield Strength: 76,000 PSI/524 Mpa
• Service Temperature: Up to 600°F/316°C
• Elongation: 37%
• Corrosion Resistance: Excellent
• Hardness: 90Rb
• Current: DCEP (DC+)
• Gas: 75% Ar/25% CO2; or 100% CO2
Technical Specifications
| Item#: | EG60180035 |
|---|---|
| Welding Process | MIG |
| Type | Flux-Cored Wire |
| Diameter | .035 " |
| Tensile Strength | 95,000 PSI |
| Yield Strength | 76,000 PSI |
| Elongation | 37 % |
| Hardness | 90 HRB |
| Shielding Gas | 100% CO2 or 75% AR/25% CO3 |
| Polarity | DCEP |
| UNSPSC #: | 23271810 |
| TAA Compliant: | Yes |
| Weight: | 37.84 lb |
