X-Tractalloy Special Bolt Extraction Ignitor Tip All Position Tensile 1230000 To 150000 Elongation 27%Polarity Ac/Dc 21Rc
(Pack of 5)

SKU:EG00450000 Item#: EG00450000

Lawson Products

A special application welding electrode designed for extracting broken bolts, studs and taps from threaded holes.
• Saves Time and Money – Reduces downtime and labor by getting parts back into service quickly
• Versatile – Will also remove broken screw extractors, taps and broken drill bits
• Strong – Tensile strength exceeds that of grades 2, 5, 8, 8.8 and 10.9 bolts and stainless steel
• IGNITOR TIP™ – For instant strike
• Nonconductive Flux – Ceramic-like coating insulates threads to prevent damage from welding
• All-position
• Tensile strength
– As deposited: 123,000 PSI/848 Mpa
– Work Hardened: 150,000 PSI/1034 Mpa
• Hardness: 21 Rc
• Elongation: 27%
• Impact Strength (Charpy, V-notch) – room temperature: 100 ft.-lbs./135 Joules
• Machinability: Good
• Current: AC or DC+
• Broken bolts, studs and screws (5/16'' and up)
• Broken taps and drills (5/16'' and up)
• Broken screw extractors like E-Z Outs™
• Works on any ferrous alloy including stainless, tool steel and nickel alloys
• Will remove iron or nickel based components from any metallic block or housing, including aluminum, brass and bronze
Rod Selection Guide:
• EG00420000 – Bolt Diameters 2-1/2'' – 4''
• EG00430000 – Bolt Diameters 1'' – 2-1/2''
• EG00440000 – Bolt Diameters 3/4'' – 1'
• EG00450000 – Bolt Diameters 1/2'' – 3/4''
• EG00460000 - Bolt Diameters 5/16'' – 1/2''

Check Availability

Quantity

California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov

Catalog page#: LE-124

Frequently Bought Together

Product Description

Technical Specifications

Item#:	EG00450000
Welding Process	Stick
Type	Electrode
Diameter	3/32 "
Tensile Strength	150,000 PSI
Elongation	27 %
Hardness	21 HRC
Polarity	DCRP/AC
UNSPSC #:	23271810
TAA Compliant:	Yes
Weight:	5.33 lb
