Air Brake Tubing N-2 5/32" OD Black
(Pack of
1.0)
• Single-wall extruded nylon
• Heat-stabilized and ultraviolet-resistant
• SAE J844, Type 3A
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• Applications: Windshield wiper lines, air horn lines, fuel lines, air regulated axles, pneumatic gauge lines
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog Page#: 23-12
Frequently Bought Together
Eclipse Air Brake Coil Hose Assembly 1/2" OD x 15'
Couldn't load pickup availability
Air Brake Tubing N-2 1/4" OD Green
Couldn't load pickup availability
Eclipse Air Brake Coil Hose Assembly 1/2" OD x 15'
Couldn't load pickup availability
DOT Connector Male Brass 1/2 x 1/2-14
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/4-18
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/4-18
Couldn't load pickup availability
Hose Clamp 301 SS 1-5/16 to 2-1/4"
Couldn't load pickup availability
Constant Torque Hose Clamp SS 5-1/4 to 6-1/8"
Couldn't load pickup availability
Non-Perforated Clamp 316 SS #10 3/4 to 1-1/8"
Couldn't load pickup availability
Z Series Crimp-On Hose End 1/4" x 9/16-18
Couldn't load pickup availability
Z Series Crimp-On Hose End 3/4" x 1-1/16-12
Couldn't load pickup availability
Z Series Crimp-On Hose End 5/8" x 7/8-14
Couldn't load pickup availability
Pipe Bushing Brass 1/2-14 x 3/8-18
Couldn't load pickup availability
Cable Tie 14.19" Black
Couldn't load pickup availability
Superbutt Connector 16 to 14 AWG Blue
Couldn't load pickup availability
Product Description
• Single-wall extruded nylon• Heat-stabilized and ultraviolet-resistant
• SAE J844, Type 3A
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• Applications: Windshield wiper lines, air horn lines, fuel lines, air regulated axles, pneumatic gauge lines
Technical Specifications
| Item#: | 52491 |
|---|---|
| Category/Performance | Air Brake Tubing |
| Type | N-2 |
| Size | BLACK |
| Industry Rating 1 | SAE J844, Type 3A |
| Group | Air Brake Tubing |
| Working Pressure | 150 PSI |
| O.D. | 5/32 " |
| Burst Pressure | 1,000 PSI |
| Length | 50 ft |
| Color | Black |
| Temperature | -40F to +200F |
| Bend Radius | 1/2 " |
| Hose Cover Material | Nylon |
| UNSPSC #: | 25171700 |
| TAA Compliant: | No |
| Weight: | 0.32 lb |
