Home Brake Air Brake Tubing N-2 1/4" OD Black
Brake

Air Brake Tubing, N-2 Type, Nylon, 1/4" OD, 11/64" ID, Black, 1" Bend Radius, 150PSI, SAE J844, Type 3A
(Pack of 1)

Item#: 5409

Lawson

• Single-wall extruded nylon
• Heat-stabilized and ultraviolet-resistant
• SAE J844, Type 3A
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• Applications: Windshield wiper lines, air horn lines, fuel lines, air regulated axles, pneumatic gauge lines

Read More
Check Availability

Catalog page#: 23-12

Frequently Bought Together


Zinc Steel Hydraulic Brake Lines 3/16" x 60"

Item#: 12046

Air Brake Jumper Hose Assembly 1/2" ID x 28"

Item#: 64377

Air Brake Tubing T-Hose 3/8" OD Blue

Item#: 52507

DOT Elbow Male Nylon 3/8 x 1/4-18

Item#: 91797

Hose Clamp 301 SS 1-5/16 to 2-1/4"

Item#: 86730

Miniature Clamp SS 5/16 to 7/8"

Item#: 86723

Silicone Heater/Coolant Hose Clamp 13/16 to 1-1/2"

Item#: 88720

Silicone Heater/Coolant Hose Clamp 11/16 to 1-1/4"

Item#: 88719

Silicone Heater/Coolant Hose Clamp 7/16 to 25/32"

Item#: 90781

Pipe Coupling Brass 3/8-18 x 3/8-18

Item#: 5290

DOT Connector Male Brass 1/4 x 1/4-18

Item#: 57505

DOT Elbow Male Nylon 1/4 x 1/8-27

Item#: 91794

SAE Flat Washer Thru-Hardened Steel 3/8"

Item#: 88437

Lawson Open & Shut Nut & Bolt Loosener, Rust Penetrant, SKU DA6152, 20 oz Aerosol Can

Item#: DA6152

SAE J995C Locknut with Nylon Insert Grade 8 1/4-20

Item#: 53979

Product Description

• Single-wall extruded nylon
• Heat-stabilized and ultraviolet-resistant
• SAE J844, Type 3A
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• Applications: Windshield wiper lines, air horn lines, fuel lines, air regulated axles, pneumatic gauge lines

Technical Specifications

Item#: 5409
Category / Performance Air Brake Tubing
Type N-2
I.D. 11/64 "
Size 1/4
Industry Rating 1 SAE J844, Type 3A
Group Air Brake Tubing
Working Pressure 150 PSI
Feet per Roll 100 ft
O.D. 1/4 "
Wall Thickness 1/32 "
Burst Pressure 1,200 PSI
Tube Insert 5389
Length 100 ft
Color Black
Temperature -40F to +200F
Bend Radius 1 "
Hose Cover Material Nylon
UNSPSC #: 25171700
TAA Compliant: No
Weight: 1.29 lb
