Air Brake Tubing, N-2 Type, Nylon, 5/32" OD, Yellow, 1/2" Bend Radius, 150PSI, SAE J844, Type 3A
(Pack of
1)
SKU:52496 Item#: 52496
• Single-wall extruded nylon
• Heat-stabilized and ultraviolet-resistant
• SAE J844, Type 3A
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• Applications: Windshield wiper lines, air horn lines, fuel lines, air regulated axles, pneumatic gauge lines
Couldn't load pickup availability
Catalog page#: 23-12
Frequently Bought Together
Air Brake Tubing T-Hose 1/2" OD Green
Couldn't load pickup availability
Air Brake Jumper Hose Assembly 1/2" ID x 36"
Couldn't load pickup availability
Inverted Flare Long Nut 3/16"
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 1/2 to 29/32"
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 13/16 to 1-1/2"
Couldn't load pickup availability
Hose Clamp 304 SS 1-9/16 to 2-1/2"
Couldn't load pickup availability
Super 77 Hose Clamp SS 7/8 to 1-3/4"
Couldn't load pickup availability
Fuel Line Hose 3/8" ID x 25'
Couldn't load pickup availability
Fuel Line Hose 5/16" ID x 25'
Couldn't load pickup availability
Hose Clamp 304 SS 1-13/16 to 2-3/4"
Couldn't load pickup availability
Hose Clamp 304 SS 3/4 to 1-3/4"
Couldn't load pickup availability
DOT Elbow Male Nylon 1/4 x 1/8-27
Couldn't load pickup availability
Self-Drilling Screw Hex Head 1/4-14 x 1"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Couldn't load pickup availability
Product Description
• Single-wall extruded nylon• Heat-stabilized and ultraviolet-resistant
• SAE J844, Type 3A
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• Applications: Windshield wiper lines, air horn lines, fuel lines, air regulated axles, pneumatic gauge lines
Technical Specifications
| Item#: | 52496 |
|---|---|
| Category / Performance | Air Brake Tubing |
| Type | N-2 |
| Size | YELLOW |
| Industry Rating 1 | SAE J844, Type 3A |
| Group | Air Brake Tubing |
| Working Pressure | 150 PSI |
| Feet per Roll | 50 ft |
| O.D. | 5/32 " |
| Burst Pressure | 1,000 PSI |
| Tube Insert | - |
| Length | 50 ft |
| Color | Yellow |
| Temperature | -40F to +200F |
| Bend Radius | 1/2 " |
| Hose Cover Material | Nylon |
| UNSPSC #: | 25171700 |
| TAA Compliant: | Yes |
| Weight: | 0.5 lb |
