Air Brake Tubing T-Hose, Nylon, 1/2" OD, 3/8" ID, Black, 2" Bend Radius, 150PSI, SAE J844, Type 3B
(Pack of
1)
• Nylon inner tube and outer cover
• One layer open polyester reinforcement
• SAE J844, Type 3B
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• SAE-approved for replacement of copper and steel tubing in all tractor-trailer applications except jumper lines from frame to axle and tractor-to-trailer hose connections
• Applications: Air gauge lines, gas and diesel fuel lines, antifreeze, main cab air supply, shift control line
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog page#: 23-12
Frequently Bought Together
Air Brake Hose End Fitting Assembly Kit 1/2"
Couldn't load pickup availability
Air Brake Tubing T-Hose 1/2" OD Red
Couldn't load pickup availability
Inverted Flare Long Nut 3/16"
Couldn't load pickup availability
DOT Connector Male Brass 3/8 x 1/4-18
Couldn't load pickup availability
Hose Clamp 301 SS 1-13/16 to 2-3/4"
Couldn't load pickup availability
Super 77 Miniature Hose Clamp SS 5/16 to 7/8"
Couldn't load pickup availability
Super 77 Hose Clamp SS 7/8 to 1-3/4"
Couldn't load pickup availability
Super 77 Hose Clamp SS 7/16 to 1 In"
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 1/2 to 29/32"
Couldn't load pickup availability
Pipe Street Elbow Brass 90° 3/8-18 x 3/8-18
Couldn't load pickup availability
DOT Swivel Elbow Male 360° Brass 3/8 x 1/4-18
Couldn't load pickup availability
Super 77 Hose Clamp SS 5/8 to 1-1/4"
Couldn't load pickup availability
Lawson Open & Shut Nut & Bolt Loosener, Rust Penetrant, SKU DA6152, 20 oz Aerosol Can
Couldn't load pickup availability
PTO Pin Lock 1/4 x 2-1/2"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Product Description
• Nylon inner tube and outer cover• One layer open polyester reinforcement
• SAE J844, Type 3B
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Working pressure: 150 PSI
• SAE-approved for replacement of copper and steel tubing in all tractor-trailer applications except jumper lines from frame to axle and tractor-to-trailer hose connections
• Applications: Air gauge lines, gas and diesel fuel lines, antifreeze, main cab air supply, shift control line
Technical Specifications
| Item#: | 5412 |
|---|---|
| Category/Performance | Air Brake Tubing |
| Type | T-Hose |
| I.D. | 3/8 " |
| Size | 1/2 |
| Industry Rating 1 | SAE J844, Type 3B |
| Group | Air Brake Tubing |
| Working Pressure | 150 PSI |
| Feet per Roll | 50 ft |
| O.D. | 1/2 " |
| Wall Thickness | 1/16 " |
| Burst Pressure | 950 PSI |
| Tube Insert | 81180 |
| Length | 50 ft |
| Color | Black |
| Temperature | -40F to +200F |
| Bend Radius | 2 " |
| Hose Reinforcement | Polyester |
| Hose Cover Material | Nylon |
| Inner Tube Material | Nylon |
| UNSPSC #: | 25171700 |
| TAA Compliant: | No |
| Weight: | 2.0 lb |
Product Restrictions
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
