Cold Shrink Tubing, 250 to 400 MCM, Black, 1.38" ID Before and 0.67" ID After Shrinkage, 6" Length
(Pack of
1)
SKU:29169 Item#: 29169
• Does not require heat to install – remove (unwind) the plastic core and tubing will shrink to seal the connection
• Safe and simple – perfect for installations where heat or flame can’t be used
• EPDM rubber seals tight and retains resiliency and pressure on the connection
• Water-resistant – meets ANSI C119.1 water seal requirements
• Use as primary insulation on solid rubber and plastic-insulated wire and cable; rated to 1,000V
• Use for physical protection and as a moisture seal for couplings, hoses, connections and terminal lugs
• For cable jacket and sheath repairs
Note: Do not cut the length of the tubing. It is intended to be used full length.
Couldn't load pickup availability
Catalog page#: 17-43
Frequently Bought Together
Cold Shrink Tubing 10 to 1/0 AWG Black
Couldn't load pickup availability
Cold Shrink Tubing 2/0 to 250 MCM Black
Couldn't load pickup availability
Cold Shrink Tubing 500 to 800 MCM Black
Couldn't load pickup availability
Cable Tie 14.19" Black
Couldn't load pickup availability
Cable Tie 7.31" Black
Couldn't load pickup availability
Butt Connector 12 to 10 AWG Clear
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 3/8"
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M8
Couldn't load pickup availability
Split Wire Loom Polyethylene Black 0.5" ID 25'
Couldn't load pickup availability
Split Wire Loom Polyethylene Black 0.35" ID
Couldn't load pickup availability
Heat Shrink Tubing 22 to 18 AWG Red
Couldn't load pickup availability
Product Description
• Does not require heat to install – remove (unwind) the plastic core and tubing will shrink to seal the connection• Safe and simple – perfect for installations where heat or flame can’t be used
• EPDM rubber seals tight and retains resiliency and pressure on the connection
• Water-resistant – meets ANSI C119.1 water seal requirements
• Use as primary insulation on solid rubber and plastic-insulated wire and cable; rated to 1,000V
• Use for physical protection and as a moisture seal for couplings, hoses, connections and terminal lugs
• For cable jacket and sheath repairs
Note: Do not cut the length of the tubing. It is intended to be used full length.
Technical Specifications
| Item#: | 29169 |
|---|---|
| Wire Gauge Coverage | 250-400kcmil |
| I.D. Before Shrinkage | 1.38 " |
| I.D. After Shrinkage | 0.67 " |
| Length | 6 " |
| Voltage | 1000 V |
| Approvals | Meets ANSI C119.1 water seal requirements |
| Style | Cold shrink tubing |
| Type | Torches and cold shrink tubing |
| UNSPSC #: | 40183000 |
| TAA Compliant: | Yes |
| Weight: | 0.15 lb |
