Cold Shrink Tubing 500 to 800 MCM Black
(Pack of
1.0)
• Does not require heat to install – remove (unwind) the plastic core and tubing will shrink to seal the connection
• Safe and simple – perfect for installations where heat or flame can’t be used
• EPDM rubber seals tight and retains resiliency and pressure on the connection
• Water-resistant – meets ANSI C119.1 water seal requirements
• Use as primary insulation on solid rubber and plastic-insulated wire and cable; rated to 1,000V
• Use for physical protection and as a moisture seal for couplings, hoses, connections and terminal lugs
• For cable jacket and sheath repairs
Note: Do not cut the length of the tubing. It is intended to be used full length.
Couldn't load pickup availability
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
Catalog page#: 17-43
Frequently Bought Together
Cold Shrink Tubing 2/0 to 250 MCM Black
Couldn't load pickup availability
Cable Tie 13.38" Black
Couldn't load pickup availability
Cable Tie 13.38" Black
Couldn't load pickup availability
180-degree Wide Beam Head Light with Side Light
Couldn't load pickup availability
Utility Knife, Folding , 4" Closed
Couldn't load pickup availability
Cross-Over Socket Extension Set, 3/8" Drive, 3 Piece
Couldn't load pickup availability
Lawson Open & Shut Nut & Bolt Loosener, Rust Penetrant, SKU DA6152, 20 oz Aerosol Can
Couldn't load pickup availability
Split Wire Loom Polyethylene Black 0.5" ID
Couldn't load pickup availability
Heat Shrink Tubing 8 to 2 AWG Clear
Couldn't load pickup availability
Heat Shrink Tubing 4 to 2/0 AWG Black
Couldn't load pickup availability
Product Description
• Does not require heat to install – remove (unwind) the plastic core and tubing will shrink to seal the connection• Safe and simple – perfect for installations where heat or flame can’t be used
• EPDM rubber seals tight and retains resiliency and pressure on the connection
• Water-resistant – meets ANSI C119.1 water seal requirements
• Use as primary insulation on solid rubber and plastic-insulated wire and cable; rated to 1,000V
• Use for physical protection and as a moisture seal for couplings, hoses, connections and terminal lugs
• For cable jacket and sheath repairs
Note: Do not cut the length of the tubing. It is intended to be used full length.
Technical Specifications
| Item#: | 29170 |
|---|---|
| Wire Gauge Coverage | 500-800kcmil |
| I.D. Before Shrinkage | 1.94 " |
| I.D. After Shrinkage | 0.95 " |
| Length | 6 " |
| Voltage | 1000 V |
| Approvals | Meets ANSI C119.1 water seal requirements |
| Style | Cold shrink tubing |
| Type | Torches and cold shrink tubing |
| UNSPSC #: | 40183000 |
| TAA Compliant: | Yes |
| Weight: | 0.26 lb |
Product Restrictions
California Proposition 65: Not Applicable
www.P65Warnings.ca.gov
