Cool Steel All Position Vertical Down Elongation 30% Polarity Dcep/Ac Tensile Up To 150000 Will Work Harden To 37Rc Ignitor Tip
(Pack of
5)
SKU:EG00550000 Item#: EG00550000
A multi-steel electrode with a fast-freeze coating to give the welder unparalleled control in the vertical down position.
• Versatile – Welds all weldable grades of steels: Cast steel, mild steel, stainless steel, manganese steel, high-strength steel, tool steel, spring steel or any combination of these
• Minimum heat requirements – runs at low amps to reduce distortion
• Designed for all-position welding — even vertical down
• IGNITOR TIP™ for instant strike
• Superior strength and crack resistance
• Tensile strength:
– As deposited: 104,000 PSI/717 MPa
– Work hardened: 150,000 PSI/1034 MPa
• Hardness: – As deposited: 97 Rb
• Work Hardened: 37 Rc
• Elongation: 30%
• Heat Resistance: Good
• Corrosion Resistance: Very good
• Crack Resistance: Excellent
• Chemical Resistance: Very good
• Impact Strength: 100 ft.-lbs. @ -75°F/-59°C
• Machinablilty: Excellent
• Current: DC or AC
Frequently Bought Together
Dissimilar Steel Stick Rod Electrode Kit
Couldn't load pickup availability
X-Tractalloy Welding Electrode Non-Conductive Flux 3/32 5/64
Couldn't load pickup availability
333 Dissimilar Steel Stick Rod Electrode 1/8"
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Clear
Couldn't load pickup availability
High Solids Paints Gloss Black
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 1/4"
Couldn't load pickup availability
Oxy Acetylene Fuel Gas Single Flint Striker
Couldn't load pickup availability
Oxy Acetylene Fuel Gas Single Replacement Flint
Couldn't load pickup availability
176 Extreme Abrasion With Impact 1/4X18IN
Couldn't load pickup availability
ER70S-6 Mild/Carbon Steel MIG Welding Wire 0.03"
Couldn't load pickup availability
331 Mild and Carbon Steel MIG Welding Wire 0.03"
Couldn't load pickup availability
321 Mild and Carbon Steel MIG Welding Wire 0.035"
Couldn't load pickup availability
Product Description
A multi-steel electrode with a fast-freeze coating to give the welder unparalleled control in the vertical down position.• Versatile – Welds all weldable grades of steels: Cast steel, mild steel, stainless steel, manganese steel, high-strength steel, tool steel, spring steel or any combination of these
• Minimum heat requirements – runs at low amps to reduce distortion
• Designed for all-position welding — even vertical down
• IGNITOR TIP™ for instant strike
• Superior strength and crack resistance
• Tensile strength:
– As deposited: 104,000 PSI/717 MPa
– Work hardened: 150,000 PSI/1034 MPa
• Hardness: – As deposited: 97 Rb
• Work Hardened: 37 Rc
• Elongation: 30%
• Heat Resistance: Good
• Corrosion Resistance: Very good
• Crack Resistance: Excellent
• Chemical Resistance: Very good
• Impact Strength: 100 ft.-lbs. @ -75°F/-59°C
• Machinablilty: Excellent
• Current: DC or AC
Technical Specifications
| Item#: | EG00550000 |
|---|---|
| Welding Process | Stick |
| Type | Electrode |
| Diameter | 3/32 " |
| Tensile Strength | 150,000 PSI |
| Yield Strength | 104,000 PSI |
| Elongation | 30 % |
| Hardness | 37 HRC |
| Polarity | DCEP |
| UNSPSC #: | 23271810 |
| TAA Compliant: | Yes |
| Weight: | 6.01 lb |
