H.D. Plain Trolley, 1 Ton Cpcty
(Pack of
1)
SKU:ZZ24159H25 Item#: ZZ24159H25
Designed for demanding industrial environments, the PT Series is built with heavier gauge steel for increased durability. Larger diameter bearings and steel wheels provide smoother movement on a variety of beams. Available up to 10 ton capacities.
• Welded all-steel frame and powder coat finish provide maximum durability and protection
• Hardened steel wheels and double sealed lubricated ball bearings provide smooth movement
• Built-in bumper guards increase user safety and extend the life of the trolley
• Easily adjustable to wide-flange H-beams, standard I-beams or curved track with the included spacer washers
• Complies with OSHA regulations, ANSI / ASME B30.11 and B30.17 standards
• Certification- Load tested to 125% of capacity with certificate
Frequently Bought Together
Bandit Ratchet Lever Operated Hoist, 1-1/2 Ton, 10' Lift
Couldn't load pickup availability
Bandit Ratchet Lever Operated Hoist, 3/4 Ton, 15' Lift
Couldn't load pickup availability
1/2 Ton Hd Manual Trolley
Couldn't load pickup availability
Grade 43 Clevis Slip Hook with Latch, 1/4", 2,600 lb WLL
Couldn't load pickup availability
1" X 10' Quick Trac Retractable Ratcheting Tie Down Black 400 Lbs
Couldn't load pickup availability
Quick Link 1/4" Chain Size 880 Lb Safe Load
Couldn't load pickup availability
Nylon Cable Tie 11.75" Black
Couldn't load pickup availability
Nylon Cable Tie 15.5" Black
Couldn't load pickup availability
Butt Connector 16 to 14 AWG Clear
Couldn't load pickup availability
1/2 Ton Hd Manual Trolley
Couldn't load pickup availability
H.D.Plain Trolley,1-1/2Ton Cpcty
Couldn't load pickup availability
1 Ton Hd Manual Trolley
Couldn't load pickup availability
Product Description
Designed for demanding industrial environments, the PT Series is built with heavier gauge steel for increased durability. Larger diameter bearings and steel wheels provide smoother movement on a variety of beams. Available up to 10 ton capacities.• Welded all-steel frame and powder coat finish provide maximum durability and protection
• Hardened steel wheels and double sealed lubricated ball bearings provide smooth movement
• Built-in bumper guards increase user safety and extend the life of the trolley
• Easily adjustable to wide-flange H-beams, standard I-beams or curved track with the included spacer washers
• Complies with OSHA regulations, ANSI / ASME B30.11 and B30.17 standards
• Certification- Load tested to 125% of capacity with certificate
Technical Specifications
| Item#: | ZZ24159H25 |
|---|---|
| Manufacturer Model #: | 1-PT |
| Style | Manual |
| Series | PT |
| Load Capacity | 2,200 lb |
| Beam Flange Width | 3 - 8 " |
| Beam Height | 4 - 19 " |
| Curve Radius Min. | 39 " |
| UNSPSC #: | 27000000 |
| TAA Compliant: | No |
