Mid-Range Panel-Mount Circuit Breaker, Type I Automatic Reset, 25 Amps, 30 Volts DC, Rounded Profile Body
(Pack of 1)

Item#: 50267

Lawson Products

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Read More
Check Availability

Catalog page#: 19-14

Frequently Bought Together


Post-Style Circuit Breaker with Bracket 25A 12V

Item#: 89106

Post-Style Circuit Breaker with Bracket 15A 12V

Item#: 89104

ATC Circuit Breaker Type I 25A 12V

Item#: 29853

MINI Fuse 20A Yellow

Item#: 95704

ATO/ATC Fuse 10A Red

Item#: 83027

Tru-Shrink Heat Shrink Tubing 8 to 1 AWG Black

Item#: 86503

MINI In-Line Fuse Holder with Cap 32V 20A

Item#: 98619

MINI Add-A-Circuit

Item#: 58332

MICRO2 Series Blade Fuse 25A Clear

Item#: 1419708

Locknut with Nylon Insert Grade 8 5/16-18

Item#: 53980

PTO Pin Lock 1/4 x 2-1/2"

Item#: 64348

SAE Flat Washer Thru-Hardened Steel 5/16"

Item#: 88436

Product Description

• Available in either Type I Automatic Reset or Type III Manual Reset with push-to-trip feature
• Rounded profile body and cover boss allow for 3-hole panel cutout mounting
• Standard mounted centers, 8–32 threaded mounting inserts
• Voltage rating: 32V DC, for use on 6V, 12V and 24V systems• Ignition protected (ABYC E-9/SAE J1171)
• For either drop-in or rear access mounting
• Applications include marine, RV and agricultural vehicles

Technical Specifications

Item#: 50267
Style Mid-Range Panel-Mounted Circuit Breakers
Amperage 25 A
Volts 32 DC
Approvals Ignition protected (ABYC E-9/SAE J1171)
Description Type I Automatic Reset
Type Electrical
UNSPSC #: 39121601
TAA Compliant: Yes
Weight: 0.09 lb
