Turnbuckle, Jaw and Eye, Galvanized, 3/8" x 6"
(Pack of 1.0)

Chicago Hardware

• Turnbuckles can be used to apply tension to wire rope or cable
• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class H
• Apply load to the center of end attachment eyes – do not side load eyes
CAUTION: Do not exceed working load limits.

Check Availability

Quantity

California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov

Catalog Page#: 15-27

Frequently Bought Together

Shoulder Eyebolt, With Nut, Galvanized, 3/8" x 5"

Eyebolt, With Nut, Galvanized, 1" x 9"

Eyebolt, Machinery, Self-Colored, 7/16" x 1-3/8"

Tarp Strap Epdm Rubber with Hooks 6" Long

Cold Shut 3/16" Body 525 Lb Safe Load

Wire Rope, Steel, Bare, 7x19, 3/16", 4,200 lbs Breaking Strength

Hex Nut Grade 5 Steel 3/8-16

SAE J995C Locknut with Nylon Insert Grade 8 1/4-20

SAE Flat Washer Thru-Hardened Steel 3/8"

Turnbuckle, Aluminum, Eye and Eye, 1/4" x 2.04" Take Up

Turnbuckle, Jaw and Eye, Galvanized, 1/4" x 4"

Turnbuckle, Hook and Eye, Galvanized, 3/8" x 6"

Product Description

• Turnbuckles can be used to apply tension to wire rope or cable
• Composed of a forged body and two end fittings
• Must only be applied to loads within their working load limit
• Apply turnbuckles in a straight in-line manner only. Do not allow anything to contact the turnbuckle body or end attachment threaded shanks
• Working load limits are based on a safety factor of 5 to 1
• Meets ASTM F1145 Type 1, Grade 1, Class H
• Apply load to the center of end attachment eyes – do not side load eyes
CAUTION: Do not exceed working load limits.

Technical Specifications

Item#:	1442249
Type	Jaw and Eye
Diameter	3/8 "
Closed Length	11-1/2 "
Working Load Limit	1,200 lb
Material	Forged Steel
Finish	Galvanized
UNSPSC #:	24101611
TAA Compliant:	Yes
Weight:	0.93 lb
