201The Elite Bare High Strength Steel Copper Brass Castiron Tungsten Carbide Nickel Alloys Tensile 95000 8% Iacs Use Brazing Flux
(Pack of
5)
SKU:EG20171600 Item#: EG20171600
Flux-coated brazing alloy with high tensile strength and exceptional ductility for joining all types of metals.
• High-Strength Joints – For dependable repairs
• High Capillarity – Thin flowing action allows complete joint fills
• Low Temperature – Easy to use for most maintenance applications
• Narrow Plastic Range – Allows control of the heat input to build up, shape or flow into joints
• Versatile – Joins steel, copper, brass, bronzes, cast iron, tungsten carbide, refractory metals and nickel alloys
• Cadmium free and low fume coating
• Tensile Strength: Up to 95,000 PSI/655 Mpa
• Machinability: Excellent
• Plastic Range: Approximately 30°F/17°C
• Working Temp: Approximately 1690°F/921°C
• Electrical Conductivity: 8% IACS
• Flux Coating: Blue
Frequently Bought Together
51 High Silver Flux Coated Brazing Rod 1/16"
Couldn't load pickup availability
23 Copper and Steel Flux Coated Brazing Rod 1/8"
Couldn't load pickup availability
30 Copper and Steel Flux Coated Brazing Rod 1/16"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 3/8-16
Couldn't load pickup availability
PTO Pin Lock 1/4 x 2-1/2"
Couldn't load pickup availability
Hex Nut Grade 8 Alloy Steel 1/2-13
Couldn't load pickup availability
510 Aluminum TIG Wire 1/8"
Couldn't load pickup availability
333 Dissimilar Steel TIG Wire 3/32"
Couldn't load pickup availability
E7018 Mild/Carbon Steel Stick Electrode 3/32"
Couldn't load pickup availability
Product Description
Flux-coated brazing alloy with high tensile strength and exceptional ductility for joining all types of metals.• High-Strength Joints – For dependable repairs
• High Capillarity – Thin flowing action allows complete joint fills
• Low Temperature – Easy to use for most maintenance applications
• Narrow Plastic Range – Allows control of the heat input to build up, shape or flow into joints
• Versatile – Joins steel, copper, brass, bronzes, cast iron, tungsten carbide, refractory metals and nickel alloys
• Cadmium free and low fume coating
• Tensile Strength: Up to 95,000 PSI/655 Mpa
• Machinability: Excellent
• Plastic Range: Approximately 30°F/17°C
• Working Temp: Approximately 1690°F/921°C
• Electrical Conductivity: 8% IACS
• Flux Coating: Blue
Technical Specifications
| Item#: | EG20171600 |
|---|---|
| Welding Process | Brazing |
| Type | Flux-Coated Brazing Rod |
| Diameter | 1/16 " |
| Length | 18 " |
| Tensile Strength | 95,000 PSI |
| Color | Blue |
| UNSPSC #: | 23271804 |
| TAA Compliant: | Yes |
| Weight: | 6.26 lb |
