7355 Carbide Hard Facing Stick Rod Electrode, 51 to 61 HRC Hardness, 140 to 300 Amps, AC/DCRP Polarity, 18" Length, 1/2"
(Pack of
25)
SKU:CW1914 Item#: CW1914
Enhance the durability and performance of your equipment with the 7355 Carbide Hardfacing Stick Rod Electrode. Engineered specifically for high abrasion resistance in low to moderate impact conditions, this hardfacing electrode is ideal for earthmoving equipment, agricultural tools, and other components exposed to wear and tear. Designed for the versatility professionals need, it supports AC or DC reverse polarity and excels in out-of-position welding, making vertical and overhead applications hassle-free. Perfect for austenitic manganese steel, the 7355 ensures exceptional abrasion resistance while extending the lifespan of vital parts.
• Minimal base metal dilution
• Maximum recovery (95% versus 65% typical)
• 1/4" dia. provides good out-of-position welding
• Good edge control
Hardness: Rc 62 (2nd pass)No. of Passes: Up to threePolarity: AC or DC Reverse
Can be used for out-of-position welding
Typical Applications
• Dredge pumps
• Screw conveyors
• Chutes for transporting sand and gravel
• Bucket lips
• Skid pads
Usage ProcedureUse AC or DC reverse polarity. Direct electrode 90° to applying surface. Use 1/4" 7355 for out-of-position welding.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog page#: 13-17
Frequently Bought Together
7222 Carbide Hard Facing Stick Rod Electrode 1/4"
Couldn't load pickup availability
747 Cobalt Stick Rod Electrode 1/8"
Couldn't load pickup availability
7220 Carbide Hard Facing Stick Rod Electrode 1/2"
Couldn't load pickup availability
7310 Carbide Hard Facing MIG Welding Wire 0.045"
Couldn't load pickup availability
176 Extreme Abrasion With Impact 1/2X18IN
Couldn't load pickup availability
246 Carbide Hard Facing Stick Rod Electrode 1/2"
Couldn't load pickup availability
1100 Gouging and Cutting Stick Rod Electrode 5/32"
Couldn't load pickup availability
1100 Gouging and Cutting Stick Rod Electrode 3/16"
Couldn't load pickup availability
1/2" Cordless Drill Driver Charging Bundle
Couldn't load pickup availability
Self-Drilling Screw Hex Head #10-16 x 3/4"
Couldn't load pickup availability
Nutsetter & Bit Set, Magnetic, 22pc
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M12
Couldn't load pickup availability
510 Aluminum TIG Wire 1/16"
Couldn't load pickup availability
X-Tractalloy Welding Electrode Non-Conductive Flux 3/32 5/64
Couldn't load pickup availability
777 Stainless Steel Stick Rod Electrode 1/8"
Couldn't load pickup availability
Product Description
Enhance the durability and performance of your equipment with the 7355 Carbide Hardfacing Stick Rod Electrode. Engineered specifically for high abrasion resistance in low to moderate impact conditions, this hardfacing electrode is ideal for earthmoving equipment, agricultural tools, and other components exposed to wear and tear. Designed for the versatility professionals need, it supports AC or DC reverse polarity and excels in out-of-position welding, making vertical and overhead applications hassle-free. Perfect for austenitic manganese steel, the 7355 ensures exceptional abrasion resistance while extending the lifespan of vital parts.• Minimal base metal dilution
• Maximum recovery (95% versus 65% typical)
• 1/4" dia. provides good out-of-position welding
• Good edge control
Hardness: Rc 62 (2nd pass)No. of Passes: Up to threePolarity: AC or DC Reverse
Can be used for out-of-position welding
Typical Applications
• Dredge pumps
• Screw conveyors
• Chutes for transporting sand and gravel
• Bucket lips
• Skid pads
Usage ProcedureUse AC or DC reverse polarity. Direct electrode 90° to applying surface. Use 1/4" 7355 for out-of-position welding.
Technical Specifications
| Item#: | CW1914 |
|---|---|
| Welding Process | Stick |
| Type | Tubular |
| Diameter | 1/2 " |
| Length | 18 " |
| Base Metal | Carbide |
| Carbide Type | Chromium |
| Hardness | 51-61 HRC |
| Polarity | AC/DCRP |
| UNSPSC #: | 23271810 |
| TAA Compliant: | Yes |
| Weight: | 25.0 lb |
