DOT Compression Connector Male Brass 3/8 x 3/8"
(Pack of
5)
Simplify tough jobs with our Brass Compression Connector, the versatile solution for joining pipes and tubing without soldering or welding. Designed for plumbing, HVAC, gas lines, and hydraulic applications, this male compression fitting ensures a reliable seal while saving you time and effort. Easy to install and remove with just a spanner or wrench, it eliminates the need for heat—making it safer to use in tight or heat-sensitive spaces. Durable and efficient, it’s the go-to tool professionals trust for both convenience and quality results.
• Fittings are shipped with nuts, sleeves and inserts preassembled, ready to slip onto tubing
• Meets D.O.T. FMVSS 571.106
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Exceeds pressure requirements of automotive air brake systems
• Typical applications include air brake systems, air control and gauge lines
• Used with nylon tubing (SAE J844, Type 3)
Assembly Instructions
1. Cut tubing squarely.
2. Insert tubing into fitting until bottomed on seat.
3. Tighten nut with wrench until one thread remains visible on the fitting body; or, the nut should be screwed down finger-tight, then wrench-tightened as indicated in the table (this will allow for a number of remakes).
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Frequently Bought Together
DOT Compression Elbow Male 90° Brass 5/8 x 3/8"
Couldn't load pickup availability
DOT Compression Elbow Male 45° Brass 1/2 x 3/8"
Couldn't load pickup availability
Air Brake Tank Filler Valve Brass 1/4-18
Couldn't load pickup availability
DOT Swivel Elbow Male 90° Brass 1/2 x 1/2-14
Couldn't load pickup availability
DOT Compression Elbow Male 45° Brass 3/8 x 1/4"
Couldn't load pickup availability
DOT Union Nylon 1/2 x 1/2"
Couldn't load pickup availability
DOT Connector Male Brass 3/8 x 3/8-18
Couldn't load pickup availability
DOT Compression Connector Male Brass 1/4 x 1/8"
Couldn't load pickup availability
DOT Compression Union Brass 1/4"
Couldn't load pickup availability
Pipe Close Nipple Brass 1/2-14 x 1/2-14
Couldn't load pickup availability
Pipe Coupling Brass 1/8-27 x 1/8-27
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 13/16 to 1-1/2"
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M10
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 3/8"
Couldn't load pickup availability
Stepdown Butt Connector 16 to 14/12 to 10 AWG
Couldn't load pickup availability
Ring Tongue Terminal 16 to 14 AWG Clear #10 Stud
Couldn't load pickup availability
DOT Compression Connector Male Brass 3/8 x 1/4"
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/4-18
Couldn't load pickup availability
Product Description
Simplify tough jobs with our Brass Compression Connector, the versatile solution for joining pipes and tubing without soldering or welding. Designed for plumbing, HVAC, gas lines, and hydraulic applications, this male compression fitting ensures a reliable seal while saving you time and effort. Easy to install and remove with just a spanner or wrench, it eliminates the need for heat—making it safer to use in tight or heat-sensitive spaces. Durable and efficient, it’s the go-to tool professionals trust for both convenience and quality results.• Fittings are shipped with nuts, sleeves and inserts preassembled, ready to slip onto tubing
• Meets D.O.T. FMVSS 571.106
• Temperature range: –40°F to +200°F (–40°C to +93°C)
• Exceeds pressure requirements of automotive air brake systems
• Typical applications include air brake systems, air control and gauge lines
• Used with nylon tubing (SAE J844, Type 3)
Assembly Instructions
1. Cut tubing squarely.
2. Insert tubing into fitting until bottomed on seat.
3. Tighten nut with wrench until one thread remains visible on the fitting body; or, the nut should be screwed down finger-tight, then wrench-tightened as indicated in the table (this will allow for a number of remakes).
Technical Specifications
| Item#: | 84269 |
|---|---|
| Fitting Type | Compression - Nylon |
| Style | DOT |
| Material | Brass |
| Configuration | Male Connector |
| Connection Type A x B | Tube x Pipe |
| Fitting Dimension A | 3/8 " |
| Fitting Dimension B | 3/8-18 |
| Size | 3/8X3/8 |
| Type | Compression |
| UNSPSC #: | 25171700 |
| TAA Compliant: | No |
| Weight: | 0.49 lb |
