Home Hydraulics Hose and Tubing Barb Lok H201 Easy Couple Hose 1/4" Black 50'
Barb Lok
H201 Easy Couple Hose 1/4
H201 Easy Couple Hose 1/4

H201 Easy Couple Hose 1/4" Black 50' Neoprene Cover 1 Fiber Braid Reinforcement 300 PSI
(Pack of 50)

Item#: 1593582

Danfoss®

H201 is compatible with fuel, lubricating oils, air and water. It supports a variety of applications from machine tools to MRO programs. Easy Couple® is a well-engineered hose that provides longer uptime and more profitable, reliable use.
Temperature range: –40°F to +212°F (–40°C to 100°C)
Reinforcement: One fiber braid
Cover: Neoprene (black) vinyl nitrile (colored hoses)
Inner tube: Nitrile

Read More
Check Availability

Catalog page#: 8-140

Frequently Bought Together

Push-on/Lock-on Fiber Braided Cover Hose 5/8

Push-on/Lock-on Fiber Braided Cover Hose 3/8"

Item#: PL12100B06
H201 Easy Couple Synthetic Cover Hose 1/2

H201 Easy Couple Synthetic Cover Hose 1/2" Black

Item#: 1176718
Push-on/Lock-on Fiber Braided Cover Hose 5/8

Push-on/Lock-on Fiber Braided Cover Hose 3/4"

Item#: 12100 12
H285 Clearforce-R Food Transfer Hose 1

H285 Clearforce-R Food Transfer Hose 1/2" Clear

Item#: 41374 08
Super HubT Air/Water Hose Reel 1/2

Air/Water Hose Reel 3/8" x 50'

Item#: 20774
Push-on/Lock-on Synthetic Rubber Cover Hose 3/8

Synthetic Rubber Bar-Lok Cover Hose 3/8" Black

Item#: 1502275
Pipe Street Elbow Brass 45° 3/8-18 x 3/8-18, Pipe Street Elbow, Brass, 45°, 3/8-18 x 3/8

Pipe Street Elbow Brass 45° 3/8-18 x 3/8-18

Item#: 5314
Z Series Crimp-On Hose End 1/2

Z Series Crimp-On Hose End 1/2 x 3/4-16"

Item#: 16615
Crimp-On Hose Coupling 5/8

Crimp-On Hose Coupling 1/2" x 3/4-16

Item#: 88364KH
Hex Nut Grade 8 Alloy Steel 1-8, ANSI B18.2.2 Hex Nut, Grade 8, Alloy Steel, Zinc Finish, Coarse Thread, 1-1/2

Hex Nut Grade 8 Alloy Steel 1/4-20

Item#: A100
SAE Flat Washer Thru-Hardened Steel 5/8

SAE Flat Washer Thru-Hardened Steel 5/8"

Item#: 88441
Flat Washer Property Class 10.9 M22, Flat Washer, Property Class 10.9, Carbon Steel, M22

Flat Washer Grade 12 Thru-Hardened Steel M12

Item#: 87512

Product Description

H201 is compatible with fuel, lubricating oils, air and water. It supports a variety of applications from machine tools to MRO programs. Easy Couple® is a well-engineered hose that provides longer uptime and more profitable, reliable use.
Temperature range: –40°F to +212°F (–40°C to 100°C)
Reinforcement: One fiber braid
Cover: Neoprene (black) vinyl nitrile (colored hoses)
Inner tube: Nitrile

Technical Specifications

Item#: 1593582
Manufacturer Model #: H20104BK
I.D. 1/4 "
Working Pressure 300 PSI
Burst Pressure 1,200 PSI
Minimum Bend Radius 3 "
Weight (Lbs. / Ft.) 0.08
Vacuum Rating (Inches of Hg) 28
UNSPSC #: 40142009
TAA Compliant: No
Weight: 4.95 lb
