Push-on/Lock-on Hose, Synthetic Rubber Cover, 1 Fiber Braid Reinforcement, Black, 300PSI, 1/2" ID
(Pack of
50)
SKU:12101 08 Item#: 12101 08
Primarily for use in air hose applications, Low-Pressure Barb-Lok Hoses are also compatible with crude, fuel and lubricating oils, water, anti-freeze, and transmission fluid.
• Temperature ranges:
– Air and water: –40°F to +212°F (–40°C to +100°C)
– Oil: –40°F to +260°F (–40°C to +127°C)
• Reinforcement: One fiber braid
• Cover: Black
• Inner tube: Synthetic rubber
Use with Barb-Lok Fittings (Do not use hose clamps)
New item numbers have been added for industry standard 250 foot reels and a running change has been made for the 50 foot length item numbers. Both lengths feature a Lawson Products layline.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog page#: 8-138
Frequently Bought Together
H100 General Purpose Fiber Cover Hose 3/8" Black
Couldn't load pickup availability
H20104YW
Couldn't load pickup availability
Hydraulic Hose LOL 4LOLYXREEL
Couldn't load pickup availability
Rubber Air Hose Whip / Snubber 3/8" x 5'
Couldn't load pickup availability
Push-on/Lock-on Synthetic Rubber Cover Hose 5/8"
Couldn't load pickup availability
Rubber Air Hose Assembly 1/2" x 50'
Couldn't load pickup availability
Hose Clamp 304 SS 9/16 to 1-1/16"
Couldn't load pickup availability
DOT Union Brass 1/2 x 1/2"
Couldn't load pickup availability
Hex Head Plug Brass 1/4-18 Male NPT
Couldn't load pickup availability
USS Flat Washer Thru-Hardened Steel 5/16"
Couldn't load pickup availability
Lawson Open & Shut Nut & Bolt Loosener, Rust Penetrant, SKU DA6152, 20 oz Aerosol Can
Couldn't load pickup availability
Butt Connector 22 to 18 AWG Red
Couldn't load pickup availability
Product Description
Primarily for use in air hose applications, Low-Pressure Barb-Lok Hoses are also compatible with crude, fuel and lubricating oils, water, anti-freeze, and transmission fluid.• Temperature ranges:
– Air and water: –40°F to +212°F (–40°C to +100°C)
– Oil: –40°F to +260°F (–40°C to +127°C)
• Reinforcement: One fiber braid
• Cover: Black
• Inner tube: Synthetic rubber
Use with Barb-Lok Fittings (Do not use hose clamps)
New item numbers have been added for industry standard 250 foot reels and a running change has been made for the 50 foot length item numbers. Both lengths feature a Lawson Products layline.
Technical Specifications
| Item#: | 12101 08 |
|---|---|
| Type | Push-on/Lock-on Hose |
| I.D. | 1/2 " |
| Dash Size | -8 |
| Working Pressure | 300 PSI |
| Burst Pressure | 1,200 PSI |
| Minimum Bend Radius | 5 " |
| Inner Tube Material | Nitrile |
| Hose Reinforcement | 1 Fiber Braid |
| Hose Cover Material | Neoprene |
| Fitting Series | Barb-Lok |
| Temperature | Oil: -40F to +212F, Air: +158F, Water: +185F |
| Color | Black |
| Size | 1/2 (-8) |
| Weight (Lbs. / Ft.) | 0.15 |
| Vacuum Rating (Inches of Hg) | 28 |
| UNSPSC #: | 40142009 |
| TAA Compliant: | Yes |
| Weight: | 8.4 lb |
