Pressure Gauge Lower Mount, Glass Lens, Bronze Bourdon Tube, Black Painted Steel Outer Case, 1/4-18 Male NPT, 0 to 15PSI
(Pack of
1)
• Pressure is measured in PSI (pounds per square inch)
• Glass lens
• Bronze Bourdon pressure tube
• Brass 1/4–18 male NPT connection (lower or center back mount available)
• Range selection: choose a gauge with a pressure range twice the standard working pressure of the system
• ±2% mid-scale accuracy – Grade B (±3% accuracy over the first and last quarters of the scale)
• Temperature range: –40°F to +150°F
• Black painted steel outer case
• 2-1/2" dial
• Utility gauges provide economical, reliable service in a wide variety of applications including pumps, compressors and other equipment• Utility gauges measure positive pressure of non-corrosive gases and liquids
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog page#: 9-69
Frequently Bought Together
Filter/Regulator Combination 1/2-14 Female NPT
Couldn't load pickup availability
GL135
Couldn't load pickup availability
Pressure Gauge Center Back Mount 0 to 160PSIG
Couldn't load pickup availability
DOT Connector Male Brass 1/4 x 1/8-27
Couldn't load pickup availability
DOT Compression Connector Male Brass 3/8 x 1/4"
Couldn't load pickup availability
DOT Union Brass 1/2 x 1/2"
Couldn't load pickup availability
Hose Barb Brass 5/16" x 1/4-18
Couldn't load pickup availability
Hose Barb Brass 3/8" x 3/8-18
Couldn't load pickup availability
Water Line Coupling Nipple Brass 3/4"
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 1/4-20
Couldn't load pickup availability
Vision Pro Super
Couldn't load pickup availability
SAE J995C Locknut with Nylon Insert Grade 8 3/8-16
Couldn't load pickup availability
Product Description
• Pressure is measured in PSI (pounds per square inch)• Glass lens
• Bronze Bourdon pressure tube
• Brass 1/4–18 male NPT connection (lower or center back mount available)
• Range selection: choose a gauge with a pressure range twice the standard working pressure of the system
• ±2% mid-scale accuracy – Grade B (±3% accuracy over the first and last quarters of the scale)
• Temperature range: –40°F to +150°F
• Black painted steel outer case
• 2-1/2" dial
• Utility gauges provide economical, reliable service in a wide variety of applications including pumps, compressors and other equipment• Utility gauges measure positive pressure of non-corrosive gases and liquids
Technical Specifications
| Item#: | 29644 |
|---|---|
| Description | Pressure Gauge |
| Type | Lower Mount |
| Thread Style | Male NPT |
| Thread Size | 1/4-18 " |
| Pressure Range | 0 - 15 PSI |
| UNSPSC #: | 27131600 |
| TAA Compliant: | No |
| Weight: | 0.39 lb |
