130 Cast Weld All Position Stick Electrode/Machinable/ Non-Conductive Flux/Polarity Dcep/Ac/Tensile 60000/All Position
(Pack of 5)

SKU:EG13030000 Item#: EG13030000

Lawson Products

Special coating prevents the electrode from overheating, like conventional cast iron electrodes.
• Machinable deposits with no hard spots
• All-position even in the downhill position
• Perfect for dissimilar cast iron combinations
• Will join all weldable grades of cast iron, cast to steel and cast to stainless
• Nonconductive flux permits welding into holes or cracks without danger of side arcing
• Versatile – Welds all weldable grades of cast iron: gray, malleable, alloyed, ductile, mechanite, nodular, and Ni-Resist
• Tensile Strength: 60,000 PSI/414 Mpa
• Yield Strength: 45,000 PSI/310 Mpa
• Hardness: Up to 80 Rb
• Machinability: Excellent
• Color Match: Excellent
• Current: DCEP (DC+) or AC

Check Availability

Quantity

Frequently Bought Together

211 Cast Iron TIG Wire 3/32"

211 Cast Iron Stick Rod Electrode 5/32"

889 Cast Iron Stick Rod Electrode 5/32"

1/4" - 3/4" Cryonitride Spiral Fluted Step Drill - 3/8" Shank

Item#: DY80170030

12" Auto-Adjust Pliers

Item#: DY89310303

10" Forman's Favorite Heavy-Duty Copper & Aluminum Cable Cutter Pliers

Item#: DY89310353

Butt Connector 22 to 18 AWG Clear

High Solids Paints Gloss Black

USS Flat Washer Thru-Hardened Steel 1/4"

Oxy Acetylene Fuel Gas Single Replacement Flint

333 Dissimilar Steel TIG Wire 1/16"

ER4043 Aluminum MIG Welding Wire 0.035"

333 Dissimilar Steel Stick Rod Electrode 1/8"

338 Mild/Carbon Steel Stick Rod Electrode 1/8"

E7018 Mild/Carbon Steel Stick Electrode 1/8"

Product Description

Special coating prevents the electrode from overheating, like conventional cast iron electrodes.
• Machinable deposits with no hard spots
• All-position even in the downhill position
• Perfect for dissimilar cast iron combinations
• Will join all weldable grades of cast iron, cast to steel and cast to stainless
• Nonconductive flux permits welding into holes or cracks without danger of side arcing
• Versatile – Welds all weldable grades of cast iron: gray, malleable, alloyed, ductile, mechanite, nodular, and Ni-Resist
• Tensile Strength: 60,000 PSI/414 Mpa
• Yield Strength: 45,000 PSI/310 Mpa
• Hardness: Up to 80 Rb
• Machinability: Excellent
• Color Match: Excellent
• Current: DCEP (DC+) or AC

Technical Specifications

Item#:	EG13030000
Welding Process	Stick
Type	Stick
Diameter	5/32 "
Tensile Strength	60,000 PSI
Base Metal	Cast Iron
Hardness	80 HRB
Polarity	DCEP
UNSPSC #:	23271810
TAA Compliant:	Yes
Weight:	5.99 lb
