170 For Overlays And Build Up Wont Spall Or Mushroom Torchable Polarity Dc Or Ac Hardness 50Rc Tensile 125000 Unlimited Passes
(Pack of
5)
SKU:EG1702100B Item#: EG1702100B
Designed to provide sound weldments and overlays free of underbead cracks, which is essential for heavy buildup deposits on high-carbon and abrasion-resistant steels.
• All-Position – Allows build-up any position
• Torch Cuttable – Makes repairs easy
• High Deposition – Fast and economical
• Chrome-Moly Deposit – High-strength, high impact-resistance, heat-treatable
• Machinable
• Tensile Strength: 118,000 PSI/814 Mpa
• Yield Strength: 13,000 PSI/779 Mpa
• Hardness: 24 Rc
• Machinability: Good (carbide tools)
• Max Number of Passes: Unlimited
• Current: DC or AC
Remove fatigued metal. Preheat according to base metal type. Build up to desired dimensions using minimal amperage and heat input. Maintain short arc gap and allow to slow cool.
Frequently Bought Together
706 Hard Facing Buildup MIG Welding Wire 1/16"
Couldn't load pickup availability
706 Hard Facing Buildup Stick Rod Electrode 3/32"
Couldn't load pickup availability
706 Hard Facing Buildup Stick Rod Electrode 1/8"
Couldn't load pickup availability
7220 Carbide Hard Facing Stick Rod Electrode 3/8"
Couldn't load pickup availability
711 Carbide Hard Facing Stick Rod Electrode 5/32"
Couldn't load pickup availability
7222 Carbide Hard Facing Stick Rod Electrode 1/4"
Couldn't load pickup availability
SAE Flat Washer Thru-Hardened Steel 5/8"
Couldn't load pickup availability
Flat Washer Grade 12 Thru-Hardened Steel M10
Couldn't load pickup availability
Stepdown Butt Connector 16 to 14/12 to 10 AWG
Couldn't load pickup availability
201 Rectangular Wear Disc Plate 3 x 6 x 5/32"
Couldn't load pickup availability
331 Mild and Carbon Steel MIG Welding Wire 0.03"
Couldn't load pickup availability
345 Tool Steel TIG Wire 3/32"
Couldn't load pickup availability
Product Description
Designed to provide sound weldments and overlays free of underbead cracks, which is essential for heavy buildup deposits on high-carbon and abrasion-resistant steels.• All-Position – Allows build-up any position
• Torch Cuttable – Makes repairs easy
• High Deposition – Fast and economical
• Chrome-Moly Deposit – High-strength, high impact-resistance, heat-treatable
• Machinable
• Tensile Strength: 118,000 PSI/814 Mpa
• Yield Strength: 13,000 PSI/779 Mpa
• Hardness: 24 Rc
• Machinability: Good (carbide tools)
• Max Number of Passes: Unlimited
• Current: DC or AC
Remove fatigued metal. Preheat according to base metal type. Build up to desired dimensions using minimal amperage and heat input. Maintain short arc gap and allow to slow cool.
Technical Specifications
| Item#: | EG1702100B |
|---|---|
| Welding Process | Stick |
| Type | Electrode |
| Diameter | 5/32 " |
| Base Metal | Carbon And Alloy Steels |
| Hardness | 55 HRC |
| UNSPSC #: | 23271810 |
| TAA Compliant: | Yes |
| Weight: | 5.44 lb |
