EC115 Winner Hydraulic Hose, Synthetic Rubber, 1-Steel Braided, 1/4" ID, 0.5" OD, 50' Length, 3250PSI, EN 857 Type 1SC
(Pack of
50)
SKU:1561383 Item#: 1561383
• Agency Ratings: Meets SAE 100R1; EN 857 Type 1SC
• Fittings Certified: Z-Series
• Agency Approval: MSHA, USCG and DNV
• Construction:
– Inner Tube: Nitrile
– Reinforcement: One steel braid
– Cover: Nitrile
• Operating Temperature Range: –40°F to +212°F (–40°C to +100°C)
• Application Notes: Hydraulic system service with petroleum
and water-based fluids, for general industrial service.
Couldn't load pickup availability
California Proposition 65: WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Catalog page#: 8-10
Frequently Bought Together
SAE R2S Hydraulic Hose Rubber 0.59" x 50'
Couldn't load pickup availability
Weatherhead H280 Hydraulic Hose 1.41" x 250'
Couldn't load pickup availability
BluShield Single-Wire Pressure Washer Hose 3/8" X 100'
Couldn't load pickup availability
KH Series Crimp-On Coupling 1/2" x 1-1/16-12
Couldn't load pickup availability
MegaCrimp Crimp-On Coupling 3/4" x 1-1/16-12
Couldn't load pickup availability
Hydraulic Hose Protector 6 x 3" Yellow
Couldn't load pickup availability
DOT Compression Elbow Male 90° Brass 3/8 x 1/4"
Couldn't load pickup availability
Super 77 Hose Clamp SS 1/2 to 1-1/8"
Couldn't load pickup availability
Silicone Heater/Coolant Hose Clamp 11/16 to 1-1/4"
Couldn't load pickup availability
BluShield Single-Wire Pressure Washer Hose 3/8" X 100'
Couldn't load pickup availability
Kurt Tuff Xtra-Flex High Pressure Hydraulic Hose, 50 Foot
Couldn't load pickup availability
SAE R16S Hydraulic Hose Rubber 1.39" x 50'
Couldn't load pickup availability
Utility Knife, Folding , 4" Closed
Couldn't load pickup availability
Stepdown Butt Connector 16 to 14/12 to 10 AWG
Couldn't load pickup availability
Self-Drilling Screw Hex Head #10-16 x 3/4"
Couldn't load pickup availability
Product Description
• Agency Ratings: Meets SAE 100R1; EN 857 Type 1SC• Fittings Certified: Z-Series
• Agency Approval: MSHA, USCG and DNV
• Construction:
– Inner Tube: Nitrile
– Reinforcement: One steel braid
– Cover: Nitrile
• Operating Temperature Range: –40°F to +212°F (–40°C to +100°C)
• Application Notes: Hydraulic system service with petroleum
and water-based fluids, for general industrial service.
Technical Specifications
| Item#: | 1561383 |
|---|---|
| Manufacturer Model #: | EC11504 |
| Industrial / Hydraulic | Hydraulic |
| Type | Rubber - Steel Braided |
| Industry Rating 1 | SAE 100R1 |
| Industry Rating 2 | EN 857 Type 1SC |
| Industry Rating | MSHA, USCG and DNV |
| Manufacturer Series Number | EC115 |
| I.D. | 1/4 (-4) " |
| Hose O.D. | 0.5 " |
| Working Pressure | 3,250 PSI |
| Burst Pressure | 13,000 PSI |
| Fitting Series | Z Series |
| Bend Radius | 1.97 " |
| Inner Tube Material | Nitrile |
| Hose Reinforcement | 1 Steel Braid |
| Hose Cover Material | Nitrile |
| Minimum Temperature | -40 F |
| Maximum Temperature | 212 F |
| Length | 50 ft |
| Dash Size | -4 |
| UNSPSC #: | 40142020 |
| TAA Compliant: | No |
| Weight: | 19.0 lb |
