Home Welding Hardfacing Alloys Mod Abrasion/Mod Impacts (Martensitic) 172 Latch Bar And Dutchman Hardfacing Alloy 1/8X18
Hardfacing Alloys
172 Latch Bar And Dutchman Hardfacing Alloy 3/16X18
172 Latch Bar And Dutchman Hardfacing Alloy 3/16X18

172 Resit Frictional Metal To Metal Wear Tough Martensite Deposit Polarity Dcep Or Ac Hardness 58Rc Number Of Passes 3
(Pack of 5)

Item#: EG1724000X

Lawson Products

Extend service life on power shovel latch bars and dutchman with these long wearing hardfacing electrodes. Produces a very tough martensite deposit that will resist frictional metal-to-metal wear. Stands up to scratching, sliding and gouging abrasion while resisting moderate to heavy impact.
• Tough – Resists cracking, chipping or spalling
• All-Position – Saves time and allows in-position welding
• Super Smooth Welding Arc – Easy to use with a smooth finish
• Economical – Saves money with long lasting overlays
• Multipass Overlays – Good for buildup
• Versatile – For use on carbon and abrasion resistant alloy steels including manganese steels
• Sound Deposits – Generally does not cross-check
• Hardness: 58 Rc
• Machinability: Grind only
• Max Number of Passes: 3
• Current: DCEP (DC+) or AC
• ASTM G65 Abrasion Test: 355.8mm³ vol. loss

Read More
Check Availability

Frequently Bought Together

172 Latch Bar And Dutchman Hardfacing Alloy 3/16X18

172 Latch Bar And Dutchman Hardfacing Alloy 3/16X18

Item#: EG1722000X
706 Hard Facing Buildup MIG Welding Wire 1/16

706 Hard Facing Buildup MIG Welding Wire 1/16"

Item#: P19543
7500 Martensitic MIG Welding Wire 0.045

7500 Martensitic MIG Welding Wire 0.045"

Item#: CW5169
3Pc Adjustable/Pipe Wrench Set, 3pc, 6

3Pc Adjustable/Pipe Wrench Set

Item#: DY89310230
Interchangeable Hex Bit Set 20Pc Torx, 20 Pc, Interchangeable Torx Quick Release Hex Bit Set

Interchangeable Hex Bit Set 20Pc Metric

Item#: DY89310521
Self Igniting Butane Torch, 2500F Flame Temperature, 4.48 oz Net Wgt, 5.2” H x 4” W, Refillable

Self Igniting Butane Torch

Item#: DY80000081
172 Latch Bar And Dutchman Hardfacing Alloy 3/16X18

172 Latch Bar And Dutchman Hardfacing Alloy 3/16X18

Item#: EG1722000X
7500 Martensitic MIG Welding Wire 0.045

7500 Martensitic MIG Welding Wire 0.045"

Item#: CW5169
750 Martensitic Stick Rod Electrode 5/32

750 Martensitic Stick Rod Electrode 5/32"

Item#: CS1515
SAE Flat Washer Thru-Hardened Steel 1/4

SAE Flat Washer Thru-Hardened Steel 1/4"

Item#: 88435
Locknut with Nylon Insert Grade 8 5/16-24, Locknut with Nylon Insert, Grade 8, Alloy Steel, Yellow Zinc Finish, Fine Thread

SAE J995C Locknut with Nylon Insert Grade 8 1/2-13

Item#: 53983
IFI 100/107 Top Locknut Grade C 1-8, IFI 100/107 Top Locknut, Grade C, Alloy Steel, Zinc/Wax Finish, Coarse Thread

IFI 100/107 Top Locknut Grade C 5/8-11

Item#: 80933
Round Soapstone Holder Heavy Duty, Round Soapstone Holder, Heavy Duty, Brass, Stainless Steel Pocket Clip

Round Soapstone Holder Heavy Duty

Item#: CW1568
321 Mild and Carbon Steel MIG Welding Wire 0.035

321 Mild and Carbon Steel MIG Welding Wire 0.035"

Item#: CW1931
Oxy Acetylene Fuel and Oxygen Quick Connector, Brass, B Standard

Oxy Acetylene Fuel and Oxygen Quick Connector

Item#: CW1407

Product Description

Extend service life on power shovel latch bars and dutchman with these long wearing hardfacing electrodes. Produces a very tough martensite deposit that will resist frictional metal-to-metal wear. Stands up to scratching, sliding and gouging abrasion while resisting moderate to heavy impact.
• Tough – Resists cracking, chipping or spalling
• All-Position – Saves time and allows in-position welding
• Super Smooth Welding Arc – Easy to use with a smooth finish
• Economical – Saves money with long lasting overlays
• Multipass Overlays – Good for buildup
• Versatile – For use on carbon and abrasion resistant alloy steels including manganese steels
• Sound Deposits – Generally does not cross-check
• Hardness: 58 Rc
• Machinability: Grind only
• Max Number of Passes: 3
• Current: DCEP (DC+) or AC
• ASTM G65 Abrasion Test: 355.8mm³ vol. loss

Technical Specifications

Item#: EG1724000X
Welding Process Stick
Type Electrode
Diameter 1/8 "
Base Metal Steel To Steel
Hardness 58 HRC
Polarity DCEP
UNSPSC #: 23271810
TAA Compliant: Yes
Weight: 6.26 lb
